Input Impedance / Level
Balanced Female XLR:
1k ohms / 15 mV RMS; -34 dBu nom.;
Mic/Line Pad Switch = +6 dBu max
1/8” (3.5mm) Stereo Line: 20k ohms / 250 mV RMS; -10 dBu nom.
Output
Balanced Male XLR:
200 ohms / 500 mV RMS; -4 dBu nom.;
+14 dBu max; Caller Only
1/8” (3.5mm) Stereo:
50 ohms / 250 mV RMS; +6 dBu max
Left = Send; Right = Caller
Headphone 1/8” Stereo:
8 ohms / 250 mW
Mixed Send and Caller
Phone Line Connector: RJ11C
Ringer: 0.8B REN
Isolation: 1500 VAC
Frequency Response: Telephone Side 200 Hz-3600 Hz
Power: 120-240 VAC Power Supply
Size: 7” x 6” x 1.6” (18 x 15 x 4.2 cm)
Weight: 2.2 lbs. (1kg)
Specications
Block Diagram
13
Technical Information
Manufacturer’s Name:
Manufacturer’s
Address:
JK Audio, Inc.
1311 E 6
th
Street
Sandwich, Illinois 60548 USA
Declares that the product:
Product Name:
Model Numbers:
Broadcast Host Digital Hybrid
Broadcast Host
Conforms to the following Product Specications:
Safety:
ESD:
Emissions:
Telecom:
AS/NZS 60950.1:2003
CAN/CSA-C22.2 No. 60950-01-03
UL Standard 60950-01 1st edition
EN 55024:1998; EN 61000-3-2; EN 61000-3-3
EN 55022:1998
AS/NZS CISPR 22 (2002)
FCC Part 15, Subpart B
ICES-003
AS/ACIF S002:2005
FCC CFR 47, Part 68
TIA968 A-1, A-2, A-3, A-4
Declaration of Conformity
