Broadcast Host™ Analog Desktop Digital Hybrid
Getting to Know Your Broadcast Host
3 4 5 6 71
8 9
2
10 11
1. Call Button
Press this button to answer an incoming call or to connect your call through
the hybrid if you have used an auxiliary phone to set up the call.
2. Drop Button
Press this button to drop (hang up) a call.
3. Send 1 Level
Adjusts the signal level that you are sending down the telephone line,
through the female XLR input.
4. Send 2 Level
Adjusts the signal level that you are sending down the telephone line,
through the 3.5mm mini jack input.
5. Caller Level
Adjusts the level of the incoming caller’s audio as it is going out the output
jacks.
6. Headphone Level
Adjusts the signal level coming from the 3.5mm front panel headphone jack.
7. Headphones
The 3.5mm stereo headphone jack contains a mix of both the Send input
audio and the Caller audio.
Controls & Indicators
