Inputs & Outputs Cont’d
7. Send 2 Mono Input
3.5mm <Mono In> mini jack for signals going into the phone line.
Line level.
8. Stereo Output
3.5mm <Stereo Out> mini jack contains both Send and Caller audio
channels with levels determined by the <Send 1> and <Send 2> level
controls and the <Caller> level control. Left channel contains your
local Send audio and right channel contains the Caller’s audio from the
telephone line.
9. Remote Control Jack
8 pin modular RJ-45 jack for connection to the optional JK Audio Guest
Module 1 Remote Keypad or your broadcast console switch contacts. Do
not connect this jack to your computer network port.
10. Power Jack
For connection only to the supplied 9VDC regulated power supply.
