13
“Input Sensitivity” settings and will not be
user adjustable from the front of the vehicle.
B) Subwoofer Level Control Only:
Req uired: a source unit or processor with left,
right and dedicated subwoofer outputs.
Inp ut Connections: The main stereo pair
of source unit outputs is connected to the
“CH 1 (Left)” and “CH 2 (Right)” inputs of
the RD400/4 (select “2 Ch.” on the “Input
Mode” switch). The source unit’s dedicated
subwoofer output is connected to the
subwoofer amplifier inputs.
Res ult: with this option, the user has the ability
to control the absolute level of the subwoofer
channel relative to the HF channels, but
cannot fade the front and rear HF channels
relative to each other.
Set the subwoofer amplifier’s “Input
Sensitivity” with the source unit’s subwoofer
level control set at 3/4 of full output.
C) Front to Rear HF Fading and Subwoofer
Level Control:
Req uired: a source unit or processor with
front and rear pairs of stereo outputs plus a
dedicated subwoofer output.
Inp ut Connections: one stereo pair of source unit
outputs is connected to the “CH 1 (Left)” and
“CH 2 (Right)” inputs of the RD400/4.
The second stereo pair of source unit outputs
is connected to the “CH 3 (Left)” and “CH
4 (Right)” inputs of the RD400/4 (select
“4 Ch.” on the “Input Mode” switch). The
source unit’s dedicated subwoofer output is
connected to the subwoofer amplifier inputs.
SERVICING YOUR JL AUDIO AMPLIFIER
If your amplifier fails or malfunctions, please
return it to your authorized JL Audio dealer so
that it may be sent in to JL Audio for service.
There are no user serviceable parts or fuses inside
the amplifier. The unique nature of the circuitry
in the JL Audio amplifiers requires specifically
trained service personnel. Do not attempt
to service the amplifier yourself or through
unauthorized repair facilities. This will not only
void the warranty, but may result in the creation
of more problems within the amplifier.
If you have any questions about the installation or
setup of the amplifier not covered in this manual,
please contact your dealer or technical support.
JL Audio Technical Support:
(954) 443-1100
9:00 AM – 5:30 PM (Eastern Time Zone)
Monday - Friday
