6
Gas
SECTION II
SPECIFICATIONS/COMPONENT IDENTIFICATION
A. SPECIFICATIONS
* For non-reversing models only.
** A minimum of 3/4” pipe must be supplied to the gas inlet for each dryer.
NOTE: Manufacturer reserves the right to make changes in specifications at any time without notice or
obligation.
BASKET (TUMBLER) DIAMETER 44-1/2” 113 cm
BASKET (TUMBLER) DEPTH 24-7/8”
63.2 cm
BASKET (TUMBLER) MOTOR 1 HP*
0.746 kw
DOOR OPENING (DIAMETER) 31-3/8”
79.7 cm
BASKET (TUMBLER) VOLUME 22.4 cu. ft.
0.634 cu. m.
EXHAUST CONNECTION (DIAMETER) 10”
25.4 cm
DRYERS PER 20’/40’ CONTAINER 8/18
DRYERS PER 48’/53’ TRUCK 24/26
VOLTAGE AVAILABLE 120-460v 1ø-3ø 50/60 Hz
APPROX. WEIGHT (UNCRATED) 888 lbs
402.8 kg
APPROX. WEIGHT (CRATED) 938 lbs
425.5 kg
HEAT INPUT 204,000 btu/hr
51,408 kcal/hr
AIRFLOW 60 Hz 1,200 cfm
33.98 cmm
AIRFLOW 50 Hz 1,008 cfm
28.54 cmm
INLET PIPE CONNECTION** 3/4” F.P.T.
Shaded areas are stated in metric equivalents
