113372-16 Telephone: 01422 822282 9
2. Dryer Rear View
Illus. No. Description
1 Heating Unit
2 Electric Service Relay Box
3 Basket (tumbler) Bearing Mount Assembly
4 Idler Bearing Mount Assembly
5 Blower Motor Assembly (for reversing models only)
6 Leveling Legs (rear)
7 Basket (tumbler) (drive) Motor Assembly
8 Dryer Exhaust
