SECTION VIII
REVERSING TIMER SPIN/DWELL ADJUSTMENTS
(FOR NON-COIN DUAL TIMER MODELS ONLY)
Dual timer models with “reversing option” have an electric reversing timer, which is located in the front control
box of the dryer.
Both the dwell (stop) time and basket (tumbler) spin time are adjustable by mode selection switches located on
the electronic timer (as noted in the illustration below).
Spin Time is adjustable between 30- and 150-seconds at 12-seconds per increment.
Dwell (Stop) Time is adjustable between 5- and 10-seconds at 0.5 seconds per increment.
