SINGLE-PHASE ELECTRICAL LEAD CONNECTIONS
Black
+
Positive
or L1
White or Red
+
Neutral
or L2
Green
+
Ground
For 220-240V Applications
CAUTION: The dryer must be grounded. A ground
lug has been provided for this purpose.
Input connection wiring must be sized properly to handle the
dryer’s current draw. This information is printed on the dryer’s
rating plate.
SINGLE-PHASE ELECTRICAL LEAD CONNECTIONS
Red
+
Positive
or L1
Blue
+
Neutral
or L2
Green / Yellow
+
Ground
For 220-240V Applications CE
Three-Phase (3ø)
Wiring Connections / Hookup
The electrical input connections on all single-phase (1ø) gas
dryers are made into the rear service box located at the upper
left area of the dryer.
IMPORTANT: A strain relief must be used where the input
wiring enters the electric box.
To Next Page
