12 JLA Limited 113429-9
MAXIMUM CAPACITY (DRY WEIGHT) 75 lb
34.02 kg
TUMBLER DIAMETER 37”
93.98 cm
TUMBLER DEPTH 35-1/2”
90.17 cm
TUMBLER VOLUME 22.09 cu ft
625.52 L
TUMBLER/DRIVE MOTOR 3/4 hp
0.56 kW
BLOWER/FAN MOTOR 1/2 hp
0.37 kW
DOOR OPENING (DIAMETER) 27-3/8”
69.53 cm
DOOR SILL HEIGHT 16 ”
40.64 cm
WATER CONNECTION 3/4”-11.5 NH
(North America)
3/4” B.S.P.T.
(Outside North America)
DRYERS PER 20’/40’ CONTAINER 9 / 20
DRYERS PER 48’/53’ TRUCK 25 / 27
VOLTAGE AVAILABLE 120-240V 1ø 2w 50/60 Hz
APPROXIMATE NET WEIGHT 600 lb
272.16 kg
APPROXIMATE SHIPPING WEIGHT 620 lb
281.23 kg
AIRFLOW
60 Hz
560 cfm
15.86 cmm
50 Hz
466 cfm
13.19 cmm
HEAT INPUT 110,000 Btu/hr
27,720 kcal/hr
EXHAUST CONNECTION (DIAMETER) 8”
20.32 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
INLET PIPE CONNECTION 1/2” M.N.P.T.
1/2” F.B.S.P.T.
(CE and Australia Only
)
VOLTAGE AVAILABLE 200-416V 1,3ø 2,3,4w 50/60 Hz
APPROXIMATE NET WEIGHT 600 lb
272.16 kg
APPROXIMATE SHIPPING WEIGHT 620 lb
281.23 kg
AIRFLOW
60 Hz
560 cfm
15.86 cmm
50 Hz
466 cfm
13.19 cmm
EXHAUST CONNECTION (DIAMETER) 8”
20.32 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
OVEN SIZE
kW Btu/hr
kcal/hr
18.5 63,105
15,902
20.3 69,000
17,000
22.0 75,084
18,921
VOLTAGE AVAILABLE 120-240V 1ø 2w 50/60 Hz
APPROXIMATE NET WEIGHT 600 lb
272.16 kg
APPROXIMATE SHIPPING WEIGHT 620 lb
281.23 kg
AIRFLOW
60 Hz
560 cfm
15.86 cmm
50 Hz
466 cfm
13.19 cmm
STEAM CONSUMPTION 136 lb/hr
61.69 kg/hr
OPERATING STEAM PRESSURE 150 psi max
10.34 bar
EXHAUST CONNECTION (DIAMETER) 8”
20.32 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
BOILER HORSEPOWER (NORMAL LOAD) 4 Bhp
SUPPLY CONNECTION 3/4” F.N.P.T.
RETURN CONNECTION 3/4” M.N.P.T.
T75 Specifications __________________________________________________________________
!
Gas
Electric
Steam
Shaded areas are stated in metric equivalents 4/30/07
Note
The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.
