JLA /T75 - T20 Dryer Specifications

6 JLA Limited 113429-9
MAXIMUM CAPACITY (DRY WEIGHT) 20 lb
9.07 kg
TUMBLER DIAMETER 25-3/4”
65.41 cm
TUMBLER DEPTH 24”
60.96 cm
TUMBLER VOLUME 7-1/2 cu ft
212.38 L
TUMBLER/DRIVE MOTOR 1/4 hp
0.19 kW
BLOWER/FAN MOTOR 1/3 hp
0.25 kW
DOOR OPENING (DIAMETER) 19-3/8”
49.21 cm
DOOR SILL HEIGHT 13”
33.02 cm
WATER CONNECTION 3/4”-11 .5 NH
(North America)
3/4” B.S.P.T. (Outside North America)
DRYERS PER 20’/40’ CONTAINER 42 / 84
DRYERS PER 48’/53’ TRUCK 96 / 108
VOLTAGE AVAILABLE 120-240V 1ø 2w 50/60 Hz
APPROXIMATE NET WEIGHT 245 lb
111.13 kg
APPROXIMATE SHIPPING WEIGHT 265 lb
120.20 kg
AIRFLOW
60 Hz
230 cfm
6.51 cmm
50 Hz
191 cfm
5.40 cmm
HEAT INPUT 40,000 Btu/hr
10,080 kcal/hr
EXHAUST CONNECTION (DIAMETER) 4”
10.16 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
INLET PIPE CONNECTION 3/8” M.N.P.T.
3/8” M.B.S.P.T.
(CE and Australia Only)
VOLTAGE AVAILABLE 200-416V 1,3ø 2,3,4w 50/60 Hz
APPROXIMATE NET WEIGHT 245 lb
111.13 kg
APPROXIMATE SHIPPING WEIGHT 265 lb
120.20 kg
AIRFLOW
60 Hz
230 cfm
6.51 cmm
50 Hz
191 cfm
5.40 cmm
EXHAUST CONNECTION (DIAMETER) 4”
10.16 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
OVEN SIZE
kW Btu/hr
kcal/hr
4.1 13,843
3,488
5.0 17,065
4,300
5.4 18,430
4,644
5.6 19,112
4,816
6.1 20,819
5,246
6.5 22,184
5,590
6.8 23,208
5,848
7.4 25,255
6,364
7.5 25,597
6,450
8.1 27,644
6,966
VOLTAGE AVAILABLE 120-240V 1ø 2w 50/60 Hz
APPROXIMATE NET WEIGHT 253 lb
114.76 kg
APPROXIMATE SHIPPING WEIGHT 273 lb
123.83 kg
AIRFLOW
60 Hz
230 cfm
6.51 cmm
50 Hz
191 cfm
5.40 cmm
STEAM CONSUMPTION 45 lb/hr
20.41 kg/hr
OPERATING STEAM PRESSURE 150 psi max
10.34 bar
EXHAUST CONNECTION (DIAMETER) 4”
10.16 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
BOILER HORSEPOWER (NORMAL LOAD) 1.2 Bhp
SUPPLY CONNECTION 1/2” F.N.P.T.
RETURN CONNECTION 1/2 ” F.N.P.T.
T20 Specifications __________________________________________________________________
!
Gas
Electric
Steam
Shaded areas are stated in metric equivalents 5/1/06
Note
The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.
