Section 2 - Pre-Operation and Inspection
2-1331200345
• Verify extension posts (4) are properly positioned as shown in figure.
• Remove safety latch (5) from stow position (6) and place through support bracket (7).
• To retract extension, reverse procedure.
OZ2791
7
4
5
6
