SECTION 7 - BASIC ELECTRICAL INFORMATION & SCHEMATICS
3121671 7-47
X10
CONN
POS
WIRE
COLOR
WIRE LABEL GAUGE JACKET To
1 RED 4-65 PWR 18AWG GXL S18 (1)
2 BLK 00-40-558 GND 18AWG GXL MS647 (8)
3 RED 4-97 IGN 18AWG GXL S15 (1)
4 WHT 4-51-1 PLTFM ENABLE 18AWG GXL IP103 (2)
X126
CONN
POS
WIRE
COLOR
WIRE LABEL GAUGE JACKET To
1 WHT 4-5 POWER 18AWG GXL CO69-J1 (28)
2 WHT 4-6 RECEIVE 18AWG GXL CO69-J1 (29)
3 WHT 4-7 TRANSMIT 18AWG GXL CO69-J1 (30)
4 BLK 000-40-4 GND 18AWG GXL CO69-J1 (31)
CO69-J12
CONN
POS
WIRE
COLOR
WIRE LABEL GAUGE JACKET To
1
2
3 YEL CAN2 HI 20 AWG
J1939
CABLE
MS325 (5)
4 GRN CAN2 LO 20 AWG
J1939
CABLE
MS325 (3)
5
6 WHT 4-96 CAN2 TERM 18 AWG GXL CO69-J12 (7)
7 WHT 4-96 CAN2 TERM 18 AWG GXL CO69-J12 (6)
8 WHT 4-163 MSSO 18 AWG GXL SW531-1 (1)
LB280
CONN
POS
WIRE
COLOR
WIRE LABEL GAUGE JACKET To
1 YEL 4-54 STRB LIGHT 18 AWG GXL MS650 (3)
2 BLK 000-40-14 STRB GND 18 AWG GXL MS647 (3)
CO69-J7
CONN
POS
WIRE
COLOR
WIRE LABEL GAUGE JACKET To
1
2 WHT 4-132 PLAT MODE 18 AWG GXL S121 (1)
3 RED+ 4-169-1 MODE SOL 18 AWG GXL FC631 (46)
4 WHT 4-86 BM ANGLE SEN 1 18 AWG GXL SN471 (C)
5
6 WHT 4-133 CAN1 TERM 18 AWG GXL CO69-J7 (17)
7 WHT 4-87 BM ANGLE SEN 2 18 AWG GXL SN471 (D)
8
9 BLK 000-40-76 GND 18 AWG GXL S295 (1)
10 WHT 4-123 GND 18 AWG GXL SN476 (2)
11
12
13 YEL CAN 1 HI 18 AWG
J1939
CABLE
MS131 (12)
14 WHT 4-53 GROUND MODE 18 AWG GXL X102A (11)
15 WHT 4-52 FOOT SW 18 AWG GXL X102A (6)
16 WHT 4-118 PWR 5V 18 AWG GXL S294 (1)
17 WHT 4-133 CAN1 TERM 18 AWG GXL CO69-J7 (6)
18
19 BLK 000-40-13 GND 18 AWG GXL FC631 (1)
20
21 WHT 4-110 PROX 1 18 AWG GXL X616A (3)
22
23 WHT 4-115 CAPACITY 1 18 AWG GXL X615A (3)
24 GRN CAN 1 LO 18 AWG
J1939
CABLE
MS131 (4)
25 BLK 000-40-51 GND 18 AWG GXL GD414 (1)
26
27
28 BLK 000-40-75 GND 18 AWG GXL S469 (1)
29 RED 4-97 PWR 18 AWG GXL S15 (1)
30
31
32 WHT 4-116 POWER 12V 18 AWG GXL X479 (1)
33 WHT 4-119 PWR 12V 18 AWG GXL S468 (1)
34 WHT 4-108 VCC 18 AWG GXL SN476 (1)
35 WHT 4-92 DOS SW 18 AWG GXL X479 (2)
Figure 7-51. Turntable Harness - Sheet 5 of 14
To Next Page
