JLG E300A - Page 53

SECTION 4 - MACHINE OPERATION
3121214 – JLG Lift – 4-7
Figure 4-3. Grade and Side Slopes
LEVEL
GRADE
SIDE SLOPE
5° MAX.
NOTE: Machine shown in transport position. For
machines provided with jib (models
E300AJ and E300AJP) the position of the
jib doesn't affect the transport position
