SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121214 – JLG Lift – 6-1
SECTION 6. GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6.1 INTRODUCTION
This section of the manual provides additional necessary
information to the operator for proper operation and mainte-
nance of this machine.
The maintenance portion of this section is intended as infor-
mation to assist the machine operator to perform daily main-
tenance tasks only, and does not replace the more thorough
Preventive Maintenance and Inspection Schedule included
in the Service and Maintenance Manual.
Other Publications Available:
Service and Maintenance Manual - ANSI Spec ....... 3120772
Service and Maintenance Manual - CE Spec........... 3120887
Illustrated Parts Manual - ANSI Spec........................ 3120773
Illustrated Parts Manual - CE Spec........................... 3120888
6.2 OPERATING SPECIFICATIONS
Table 6-1. Operating specifications - E300A
Capacity: Unrestricted: 500 lbs. (227 kg)
Maximum Travel Grade, stowed
Position (Gradeability) see Figure 4-3.
25%
Maximum Travel Grade, stowed
Position (Side Slope) see Figure 4-3.
5%
Vertical Platform Height 30 ft. (9.14 m)
Horizontal Platform Reach
(Up & Over)
20 ft. (6.1 m)
Machine Width 4 ft. (1.22 m)
Turning Radius (Outside) 10 ft. (3.05 m)
Turning Radius (Inside) 5 ft. (1.52 m)
Drive Speed (High Drive)
(Above Horz.)
45-50 sec/ 200ft. (61 m)
55-68 sec/ 50 ft. (15.2 m)
Gross Machine Weight 14,500 lbs. (6,577 kg)
