SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6-4 – JLG Lift – 3121214
Dimensional Data Hydraulic Oil
NOTE: Hydraulic oils require anti-wear qualities at least API Ser-
vice Classification GL-3, and sufficient chemical stability
for mobile hydraulic system service.
NOTE: Machines may be equipped with Mobil EAL224H biode-
gradable and non-toxic hydraulic oil. This is vegetable oil
based and possesses the same antiwear and rust protec-
tion characteristics as mineral oils, but will not adversely
affect the ground water or the environment when spilled
or leaked in small amounts. Mobil EAL224H has a viscos-
ity of 34 cSt at 40° C. and viscosity index of 213. The oper-
ating temperature range of this oil is -18° C. to +83° C.
Ta b l e 6 - 5 . D i m e ns i o n a l D a t a
Turning Radius (Inside) 5 ft. (1.52 m.)
Turning Radius (Outside) 10 ft. - 0 in. (3.05 m)
Machine Height (stowed) 6 ft., 7.0 in. (2.0 m.)
Machine Length (stowed)
E30 0A
E30 0AJ/AJP
17 ft.,2 in. (5.23 m.)
18 ft., (5.48 m)
Up and Over Platform Height 13 ft.,1.0 in. (3.99 m.).
Horizontal Reach Up and Over 20 ft. (6.1 m.).
Machine Width 4 ft., (1.22 m.)
Wheel Base 6 ft., 7.25 in. (2.01 m.)
Platform Height 30 ft., 0 in. (9.14 m.)
