SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6-2 – JLG Lift – 3121214
Ground Bearing Pressure
110 psi (7.7 kg/cm
2
)
Maximum System Voltage 48 VDC
Maximum Main Relief Hyd. Pressure 2500 psi. (172.3 bars)
Table 6-2. Operating specifications - E300AJ
Capacity: Unrestricted: 500 lbs. (227 kg)
Maximum Travel Grade, stowed
Position (Gradeability) see Figure 4-3.
25%
Maximum Travel Grade, stowed
Position (Side Slope) see Figure 4-3.
5%
Vertical Platform Height 30 ft. (9.14 m
Horizontal Platform Reach
(Up & Over)
20 ft. (6.1 m)
Machine Width 4 ft. (1.22 m)
Turning Radius (Outside) 10 ft. (3.05 m)
Turning Radius (Inside) 5 ft. (1.52 m)
Table 6-1. Operating specifications - E300A
Drive Speed (High Drive)
(Above Horz.)
45-50 sec/ 200ft. (61 m)
55-68 sec/ 50 ft. (15.2 m)
Gross Machine Weight 15,400 lbs. (6985 kg)
Ground Bearing Pressure
121 psi (8.7 kg/cm
2
)
Maximum System Voltage 48 VDC
Maximum Main Relief Hyd. Pressure 2500 psi. (172.3 bars)
Table 6-2. Operating specifications - E300AJ
