Machine Operation
74
31219187
EC450AJ, EC520AJ
4.15.4 Battery Charger Indicators and Display
Table 4. Battery Charger LED Indicators
Status Charger Unit LEDs Red/Green External Indicator LEDs Red/
Green/Amber
On Charge: Less than 80% SOC Red LED Solid Red LED Solid
On Charge: 80% - 99% SOC Red LED Solid / Green LED Blinking Green LED Blinking
Balancing Active Red LED Solid / Green LED Fast
Blinking
Green LED Fast Blinking
Balancing Complete + Charge
Complete (Final Charge State)
Red LED Fast Blinking Red LED Fast Blinking (Amber once
Charge is Complete)
Charge Complete Green LED Solid Green LED Solid
Battery Heating Mode Red LED Blinking Red LED Blinking
Fault Alarm (Any Charger Related
Fault)
Red LED and Green LED Alternate
Blinking
Red LED and Green LED Alternate
Blinking
Table 5. Battery Charger Display
Status Display
Waiting to Charge (Idle - charge current and voltage
are 0)
IdL
Battery Heater htr
Charging Active
XXX%
Charging Active Charge Voltage
Charging Active Charge Current
Charging Active AHr Charge
Charging Active Charge Time Elapsed
Charging Complete
100%
Fault
Err
