The DAKAR machine cuts the following types of keys:
Security keys.
Waves keys.
Tubular keys.
FIC-2 and FIC-3 keys.
WIN-1D, WIN-2D, WIN-3D and WIN-4D keys.
JIS-4.P keys.
FO-6.P keys.
9
Clamp-holder slide, x – y axes
Head, z axis
Tracer point side tilting clamp
Milling cutter side tilting clamp
Clamp knob
Clamp-holder slide locking knob, x axis
Slide springing system drive wheel, x axis
Tracer point locking handle
Z axis head drive and locking lever
Slide drive lever, x – y axis
Bit-holder, tracer point and milling cutter
Tracer point
Milling cutter
General switch
Motor switch, 2 speeds
Light
Tool drawer
Chip guard
Keypad and calibration lights
Clamp rotation locking lever
Clamp-holder slide locking knob, x – y axes
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
The DAKAR key cutting machine is a high precision,
robust machine. It is characterised by the clamp which has
multiple different possibilities for securing keys without
pads or adapters.
See figure 2
General points
Presentation
and general aspects
1
Characteristics
of the machine
2
1.1
The DAKAR key cutting machine has been designed
taking into account the safety standards in force in
the EU.
The safety of personnel involved in handling this type
of machine is only achieved with a well designed
personnel safety programme, the implementation of a
maintenance programme and following the recommen-
dations given, as well as by complying with the safety
regulations covered in this manual.
Although the installation of the machine presents no
problems, it is best not to try and install, adjust or
operate the machine without having read this manual
first.
The machine comes inside packaging with the
following measurements:
Width = 520 mm, length = 575 mm, height = 650 mm
and 30 kg weight.
Once the machine has been unpacked, carefully
inspect it to ensure that it has not been damaged
during transportation. If any problem is found, inform
carrier immediately and do not do anything with the
machine until the carrier’s agent has carried out the
corresponding inspection.
The DAKAR key cutting machine has an identification
label giving the serial number, name and address of the
manufacturer, CE mark and year of manufacture.
See figure 1
Identification label
1.3
Transportation and packing
1.2
Families of keys
2.1
Motor: Single phase 200 W, 230 V – 50 Hz
Milling cutter: super quick-speed steel
Milling speed: 5500 and 8000 rpm
Clamps: With two securing faces and tilting 0 / 45º
Movements: On three axes with ball guides
Tool travel: X axis = 60 mm, Y axis = 60 mm and Z axis = 40 mm
Lighting: 20 watt 12V halogen light
Dimensions: Width = 310 mm, Depth = 380 mm and Height =
420 mm
Weight: 25 Kg
Technical data
2.3
Main elements of the machine
2.2
