FOUNTAIN ASSEMBLY SQ2
STEP 1
Removefountaincomponentsfromtheirboxes
andplacefountaindrumonasturdy,level
surface.Makesurethedrumislevelsothatthe
chocolatewillowproperly.
STEP 2
Placethebasinontopofthedrumatan
angleandpushdownandturnclockwise45
degreestolockthebasinwithdrum.Tocheck
thefountainislevelplaceaspiritlevelonthe
basinrimatvariouslocations(Fig.5).Ifleveling
isneeded,raiseorloweraparticularsideofthe
fountainbyadjustingthefeet.
STEP 3
Placeaugerontopofthesquarecentershaftin
themiddleofbasin(Fig.6).
STEP 4
Placethecentercolumnontothecentre
housinginthemiddleofthefountainbase(Fig.
7).Ensurethattheslotonthecolumnbaselines
upwiththelocatingpinontheinsideofthe
housing.
STEP 5
PlacetheTiersonthecentercolumn.Largeone
rstthenthemediumdishandthesmalldishlast
(Fig.8).
STEP 6
makingsurethattheaugerpinsitsinthemiddle
ofthetophatring.
Fig. 5
Fig. 8
»»
Fig. 6
Centre & Locating Pins
Fig. 7
Slot in column
