JMS TPM-02 User Manual

EN-6
DEVICE SPECIFICATIONS
Item
Specification
Device name
JMS Tongue Pressure Measurement Device
Model name
Digital Tongue Pressure Meter
Model type
TPM-02
Power supplies
AA alkaline battery × 2 or AA nickel-metal-hydride rechargeable battery × 2
Electrical
rating
Voltage
DC 3V (Two AA alkaline batteries)
DC 2.4V (Two AA nickel-metal-hydride rechargeable batteries)
Measureable
number
Approx. 2,500 times (Assuming use of a new batteries or rechargeable batteries
within one month at room temperature)
Durability
5 years (About 45,000 pressurization pump operations)
Dimensions
74 (W) × 120 (L) × 27.5 (H) mm
Internal
pressure
adjustment
Set value
19.6 kPa (Automatically displays zero after internal pressure adjustment)
Adjustment time
Within 20 seconds
Accuracy
±1.0 kPa (at the set value of internal pressure 19.6 kPa)
Measurement
Display unit
kPa
Display range
-9.9 to 99.9 kPa (when the zero is set at 19.6 kPa)
Accuracy
±1 kPa (at 0.0 to 80.0 kPa when internal pressure setting value of 19.6 kPa is set to zero.)
Display format
Digital numbers and bar graphs (Level sign indication)
Electric shock protection type
Internal power supply BF type applied parts
Drip-proof properties
IPX0
EMC
IEC 60601-1-2 : 2014 / EN IEC 60601-1-2: 2015
External output function
USB (data transmission only)
Option
Software for Tongue Pressure Measurement Data
MFDS Import Certificate No.
20-164
DESCRIPTION OF EACH PART
■ Digital Tongue Pressure Meter
1． Front view
Connecting tube port cap
Protects the connecting tube port.
Power button
Turns the power ON-OFF.
Prep / Reset Button
When the key is pressed with the power
turned on, adjusts the internal pressure
of the connected the device and the
accessories.
LCD screen
Displays tongue pressure values, etc.
Body
Outer cover of the device.
USB port cap
Protects the USB port.
