40
5.3.5-1
Operation
5.3.5 Check spin
It is good practice to perform a check spin after applying
the weights.
• Spin the wheel.
If the wheel has been balanced properly, “000” will
be displayed for both planes. To check how much
imbalance is left:
• Select the fi ne key (1) - Fig. 5.3.5-1.
• Rotate the wheel by hand.
The weight to be applied is shown on the display.
Note: The operator should decide if applying the
stated weight is necessary.
5.3.6 Results recalculation
After spinning a wheel it is possible to enter new rim
data or select another weight mode. The results are
recalculated automatically, if possible.
Selecting another weight mode:
- Between NORMAL, ALU and STATIC: no additional
steps required.
• Select “fine” Figure 5.3.5-1 (Lens) to toggle
between Weight Application Mode and Data Entry
Mode.
• State the new plane reference points.
• Apply the weight (s).
To have a recalculation done:
• Select the required weight mode. Check and/or edit
rim or plane data when necessary.
• Rotate the wheel to the left plane WAP position and
apply the weight.
• Rotate the wheel to the right plane WAP position
and apply the weight.
• Perform a check spin.
.
1
