14. Grass-catcher: as well as collecting
the grass cuttings, this is also a safety
element that stops any objects drawn
up by the blades from being thrown
outside of the machine.
15. Stone-guard or deflector (optional):
this can be fitted in place of the grass-
catcher and prevents objects drawn up
by the blades from being thrown out-
side of the machine.
16. Engine: this moves the blades and drives the wheels. Its specifications and regu-
lations for use are described in a specific manual.
17. Battery: provides the energy for starting the engine. Its specifications and regula-
tions for use are described in a specific manual.
18. Driving seat: this is where the machine operator sits. It has a sensor connected to
safety devices for detecting the presence of the operator.
19. Regulation and safety labels: give reminders on the main regaulations for work-
ing safely, each of which is explained in chapter 1.
20. Inspection hatch: for access to the battery; it is fixed by a screw and should
always be closed while the machine is in use.
IDENTIFICATION OF THE MACHINE AND COMPONENTS
