14
EN
4.7 BLADE ENGAGEMENT AND BRAKE CONTROL
The mushroom switch allows you to engage the blades using the electromagnetic
clutch:
«A» Pressed = Blades disengaged
«B» Pulled = Blades engaged
– If you engage the blades without taking the necessary safety precautions, the
engine shuts down and cannot be restarted ( 5.2).
– Blade disengagement (Pos. «A»), simultaneously activates a brake which stops their
rotation in a few seconds.
4.8 CUTTING HEIGHT ADJUSTMENT LEVER
There are seven positions for this lever (shown as «1» to «7» on the label), which corre-
spond to various heights between 3 and 8 cm.
– To go from one height to another, press the release button at the end of the lever.
4.9 LEVER FOR TIPPING THE GRASS-CATCHER
This pull-out lever tips and empties the grass-catcher. This means less work for the
operator.
CONTROLS AND INSTRUMENTS
