System 450™ Series Control Module with Ethernet Communications Installation Instructions
13
Figure 6 on page 30 provides a System 450 UI setup example.
Table 5: System 450 Sensor Setup Screen Information and Procedures (Part 1 of 2)
LCD Screen Name, Description or Function, User Action, and Example
Sensor Setup Start Screen: The Sensor Setup Start screen is the first screen displayed when you
access the System 450 setup screens. From the Sensor Setup Start screen you can navigate to the
Output Setup Start screens or the Sensor Setup screens. See Figure 6.
Note: You must set up the input sensors before you can set up the control system outputs. The Sensor
Setup Start screen is view-only; selections are not made in Setup Start screens.
1. In the Sensor Setup Start screen, press
to go to the first Sensor Type Selection screen
(Sn-1) and begin setting up the sensors in your control system.
The screen example shows the Sensors Setup Start screen with flashing dashes.
Sensor Type Selection Screens: The Sensor Type you select for an input sensor automatically
determines the setup parameters and values for each output that is set up to reference that sensor. See
Table 4 for information about System 450 sensors or transducers, Sensor Types, condition type, units of
measurement, minimum control band or proportional band, setup values, value ranges, and product code
numbers.
Note: For outputs to operate properly, the selected Sensor Type must match the sensor or transducer
model wired to the control module, and the sensor or transducer must be wired to the proper control
module input terminals.
2. In the Sn-1 Sensor Type Selection screen, press or to select the desired Sensor Type. Press
to save your selection and go to the Sn-2 Sensor Type Selection screen.
3. In the Sn-2 Sensor Type Selection screen, press or to select the desired Sensor Type. Press
to save your selection and go to the Sn-3 Sensor Type Selection screen.
Note: If your control system does not use three input sensors, simply press
while the two dashes are
flashing in a Sensor Type Selection screen to save no Sensor Type and go to the next setup screen.
4. In the Sn-3 Sensor Type Selection screen, press or to select the desired Sensor Type. Press
to save your selection and either:
• go to the Temperature Offset Setup screen for the first temperature sensor in your system.
• return to the Sensor Setup Start Screen, if your control system has no temperature sensors.
Note: On System 450 control modules with network communications, if you select the same Sensor
Type for Sn-1 and Sn-2, two additional functional sensors (Sn-d and HI-2) are available for selection
when you set up the control system outputs. If you select the same Sensor Type for Sn-1, Sn-2 and Sn-3,
then functional sensor HI-3 is also available for selection when you set up outputs. See High Input-Signal
Selection on page 15 and Differential Control on page 15 for more information.
The screen examples show Sn-1 with the P 500 Sensor Type selected; Sn-2 with the °F Sensor Type
selected; and Sn-3 with the no Sensor Type selected.
