25
RH
W2
W1
RC
C
O
Y2
Y1
G
AUX
HVAC System Control Board
Fan
Aux Heat
Stage 1
Compressor
Command
Stage 1
RCC
Reversing
Valve
GW1RCC Y1 O
C R Run
Furnace Powered
AUX Device
Furnace
Heat Pump
One Stage Heat Pump with One Stage Auxiliary Heat
GLAS smart thermostat installation instructions -
©
2018 Johnson Controls
