OPTIONAL PARTS
TC-16001-rev.5
3-5
3.4 Wind Guard: WSP-160A
This Wind Guard is to protect the outdoor unit from strong winds.
24-13/16 (630)
<22-3/16 (564)>
2 x φ1/4 (φ7)
10-13/16
(275)
8-7/8
(225)
27-11/16 (703)
28-5/8 (727)
6-15/16
(176)
4 x φ1/4 (φ7)
(Both Side)
<22-3/16 (564)>
18-7/8 (480)
11/16
(18)
1-3/4
(45)
< Wind Guard (Upper) >
< Securing Stay
>
< Wind Guard (Lower)
>
24-3/4 (628)
18-7/8 (480)
4 x φ1/4 (φ7)
25-5/8 (651)
26-13/16 (681)
<22-3/16 (564)>
9-3/16
(233)
8-7/8
(225)
6-15/16
(176)
4 x φ1/8 (φ3.8)
(Both Side)
23-15/16 (608)
inch (mm)
< >: Installation Dimension
