Johnson Controls JMW Series - Model Nomenclature

JMW-Series
Rev.: February 28, 2023
THE SMART SOLUTION FOR ENERGY EFFICIENCY
Installation, Operation, Maintenance
3
Model Nomenclature
J M W A0 3 6 CG 1 0 C 0 C S
1 2 3 4 5 6 7
8
9 10 11 12 13 14 15
JM = JOHNSON CONTROLS
Water to Water
MODEL TYPE
W = WATER TO WATER HEAT PUMP
CONFIGURATION
UNIT SIZE
036 - E,F,G,H
REVISION LEVEL
A = CURRENT 036
B = CURRENT 060, 120, 170, 340
VOLTAGE
CONTROLS
CABINET INSULATION
1 = EXTENDED RANGE
HOT WATER GENERATOR OPTIONS
(JMW036-120 ONLY)
C = COPPER
SOURCE WATER COIL OPTIONS
N = CUPRO-NICKEL
C = COPPER
LOAD WATER COIL OPTIONS
N = CUPRO-NICKEL
S = STANDARD
0 = NONE
RESERVED-FOR FUTURE OPTIONS
0 = NONE
060 - F,G,H,N
120 - F,G,H,N
170 - F,H,N
340 - F,H,N
2 = EXTENDED RANGE w/Sound Attenuation Package
2 = HWG (COIL ONLY)
G = 208-230/60/1
E = 265/60/1
H = 208-230/60/3
F = 460/60/3
N = 575/60/3
AVAILABLE
VOLTAGES
{
Control
CXM2
DXM2.5
CXM2 w/ MPC
DXM2.5 w/ MPC
C
D
N
P
A
B
R
S
w/oDisconnect w/Disconnect
