LX Series Free Programmable LX-PRGxxx-11 Controllers Installation Instructions 13
Maintenance
Each controller requires minimal maintenance, but it is
important to:
• clean the outside of the front plate and the inside of
the back plate with a dry cloth
• verify the tension of all wires and cables each time
you service the controller
Disposal
The Waste Electrical and Electronic Equipment
(WEEE) Directive sets regulations for the recycling and
disposal of products. The WEEE 2002/96/EG Directive
applies to stand-alone products that can function on
their own and are not a part of another system or piece
of equipment. For this reason, Johnson Controls®
products are exempt from the WEEE Directive.
Nevertheless, they are marked with the WEEE symbol,
indicating the devices are not disposed with municipal
waste.
Dispose of products at the end of their useful life
according to local regulations and the WEEE Directive.
Troubleshooting
Table 5 describes some troubleshooting scenarios.
!
CAUTION: Risk of Electric Shock.
Disconnect the power supply before
making any electrical connections to
avoid electric shock.
MISE EN GARDE : Risque de décharge
électrique.
Débrancher l'alimentation avant de
réaliser tout raccordement électrique afin
d'éviter tout risque de décharge
électrique.
Table 5: Troubleshooting (Part 1 of 3)
Problem Possible Cause Solution
Controller is powered
but does not turn on.
Fuse Is Blown Disconnect power from the controller and check the fuse integrity.
Reconnect power.
Power Supply Polarity Verify that consistent polarity is maintained between all controllers
and the transformer. Ensure that the COM terminal of each controller
is connected to the same terminal on the secondary side of the
transformer. See Figure 4 and Figure 3.
Controller cannot
communicate on the
LONWORKS network.
Absent or Incorrect
Supply Voltage
1. Check power supply voltage between 24 VAC/DC ±15% and
COM pins, and ensure that it is between acceptable limits.
2. Check for tripped fuse or circuit breaker.
Overloaded Power
Transformer
Verify the transformer is powerful enough to supply all controllers.
Network Not Wired
Properly
Check that the wire connections are correct.
Absent or Incorrect
Network Termination
Check the network terminations.
