LX Series Free Programmable LX-PRGxxx-11 Controllers Installation Instructions 15
Hardware output is not
operating correctly.
Fuse has blown (auto
reset fuse)
Disconnect the power and outputs terminals. Then wait a few
seconds to allow the auto-reset fuse to cool down. Check the power
supply and the output wiring if necessary.
Output Wiring Problem Check that the wiring is correct according to this manual and
according to the peripheral device's manufacturer.
Configuration Problem Using the controller configuration wizard (LX-GPI), check the
configuration of the input. Refer to the controller's user guide for
more information.
0 to 10 V Output, 24 VAC
Powered Actuator is Not
Moving
Check the polarity of the 24 VAC power supply connected to the
actuator while connected to the controller. Reverse the 24 VAC wire
if necessary.
Table 5: Troubleshooting (Part 3 of 3)
Problem Possible Cause Solution
