Johnson Controls LX Series Installation Instructions

LX Series Free Programmable LX-PRGxxx-11 Controllers Installation Instructions20
Outputs Universal Outputs: 8
Universal Output Characteristics:
0-10 VDC linear; digital 0 to12 VDC (on/off), PWM, or floating (0 to 12 VDC) 0 to 20 mA
(jumper configurable); software configurable.
Built-in snubbing diode to protect against back EMF (for example when used with a 12
VDC relay).
PWM control: adjustable period from 2 to 65 seconds
Floating control:
minimum plus on/off: 500 ms
adjustable drive time period
60 mA maximum at 12 VDC (60
°C; 140°F)
Load Resistance: minimum resistance 200 ohms for 0 to 10 VDC and
0 to 12 VDC outputs, maximum 500 ohm for 0 to 20 mA output
Auto reset fuse
60 mA at 60
°C (140°F)
100 mA at 20
°C (68°F)
Output Resolution: 10-bit digital/does analog converter
Electromagnetic Compatibility CE Emission: EN61000-6-3: 2007 Generic standards for residential, commercial, and
light-industrial environments (pending).
CE Immunity: EN61000-6-1: 2007; Generic standards for residential, commercial, and
light-industrial environments (pending).
LN Series Communicating
Sensor
Communication: RS-485
Number of sensors per controller: up to 12, in daisy-chain configuration
Cable: Cat 5e, 8 conductor twisted pair
Connector: RJ-45
Compliance:
United States UL Listed, File E107041, CCN PAZX7,
Under UL 916, Energy Management Equipment
FCC Compliant to CFR 47, Part 15, Subpart B, Class A
Canada UL Listed, File E107041, CCN PAZX7,
Under CAN/CSA C22.2 No. 205, Signal Equipment
Industry Canada, ICES-003
Europe CE Mark – Johnson Controls, Inc., declares that the products are in compliance with the
essential requirements and other relevant provisions of the EMC Directive 2004/108/EC.
LX-PRG300-11 (Part 1 of 2)
