LX Series Free Programmable LX-PRGxxx-11 Controllers Installation Instructions 5
Figure 7: LX-PRG4x0-11 and 6x0-11
Controller Jumper Location
* Factory-default positions
L
ON
W
ORKS
Network Board
Universal Outputs (UO)
0-10V / 0-20mA Select
0-10V* 0-20mA
Universal Inputs (UI)
0-20mA Enable / Disable
0-20mA
Disable*
0-20mA
Enable
PRG6x0-12 ONLY:
Subnetwork EOL
Termination
Subnet
Port
EOL Off
(Disabled)*
EOL On
(Enabled)
EOL Off
(Disabled)*
EOL On
(Enabled)
OR
Wireless
Port
Typical locations: Quantity may vary according to controller model
Net to Subnet Settings
Enabled Disabled*
