Refer to the Controller Tool Help (LIT-12011147) and
Controller Provisioning with Tools for detailed information
about commissioning the controllers.
Firmware package file
The MS-FCP-0 equipment controller firmware package
files are required for CCT to configure and commission
the controllers. The firmware package files also allow you
to upgrade an existing controller to the latest firmware
release available for that controller.
Beginning at CCT Release 13, the firmware package files
are orderable separately; they are not included with CCT.
They are obtained from the Metasys software licensing
portal, and are loaded and licensed on the computer/
server that is running CCT.
For additional information about the firmware
package files, refer to the CCT Installation Instructions
(LIT-12011259).
Setting a preloaded application
You can configure a CVM/CVE controller to use one of the
14 preloaded applications using the MAP Gateway release
5.1 or later. Refer to Table 9 for the list of preloaded
applications. The CVM/CVE controllers ship with the
Cooling Only W/C Adjust application set by default.
Table 9: Preloaded Standard Applications
Application Name Description
Cooling Only W/C Adj Single Duct Cooling Only, Warm/Cool Adjust
Cooling Only SP Adj Single Duct Cooling Only, Setpoint Adjust
Incr HW Reheat W/C Adj Single Duct Incremental Hot Water Reheat, Warm/Cool Adjust
Incr HW Reheat SP Adj Single Duct Incremental Hot Water Reheat, Setpoint Adjust
Elec Reheat 1-3 Stg W/C Adj Single Duct Electric Staged Reheat with 1, 2, or 3 Stages, Warm/Cool
Adjust
Elec Reheat 1-3 Stg Series Fan W/C Adj Single Duct Electric Staged Reheat with 1, 2, or 3 Stages, Single Speed
Series Fan, Warm/Cool Adjust
Elec Reheat 1-3 Stg Series Fan SP Adj Single Duct Electric Staged Reheat with 1, 2, or 3 Stages, Single Speed
Series Fan, Setpoint Adjust
Elec Reheat 1-3 Stg Parallel Fan W/C Adj Single Duct Electric Staged Reheat with 1, 2, or 3 Stages, Parallel Fan,
Warm/Cool Adjust
Elec Reheat 1-3 Stg Parallel Fan SP Adj Single Duct Electric Staged Reheat with 1, 2, or 3 Stages, Parallel Fan,
Setpoint Adjust
Incr HW Reheat Series Fan W/C Adj Single Duct Incremental Hot Water Reheat, Single Speed Series Fan,
Warm/Cool Adjust
Incr HW Reheat Parallel Fan W/C Adj Single Duct Incremental Hot Water Reheat, Parallel Fan, Warm/Cool
Adjust
SCR Elec Reheat W/C Adj Single Duct SCR Electric Reheat/Proportional Heating Valve, Warm/
Cool Adjust
SCR Elec Reheat Series Fan W/C Adj Single Duct SCR Electric Reheat/Proportional Heating Valve, Single
Speed Series Fan, Warm/Cool Adjust
SCR Elec Reheat Parallel Fan W/C Adj Single Duct SCR Electric Reheat/Proportional Heating Valve, Parallel
Fan, Warm/Cool Adjust
Note: All applications use the Imperial unit of
measure.
Note: Warm/Cool Adjust applications also support
sensor only.
Note: These applications only supports the NS8000
series sensors. Older netsensors are no longer
supported.
Troubleshooting equipment controllers
Table 10 provides LED status indicator information for troubleshooting the controller. General troubleshooting provides
some additional troubleshooting information for possible problems.
Note: If you experience short circuits in the 24 VAC power supply causing protective devices such as breakers or
fuses to trip, make sure that the power connections on the controller are not reversed. The most common cause
of this problem is when the 24 VAC power supply on the controller is reversed but not reversed on a connected
secondary device.
M4-CV Series VAV Box Controllers Installation Guide 17
