M9106-xGx-2 Series Electric Non-Spring Return Actuators Installation Instructions 7
Technical Data
Product
M9106-xGx-2 Series Electric Non-Spring Return Actuators
Power Requirements AGx: 20 to 30 VAC at 50/60 Hz; 2.5 VA supply, Class 2
IGx: 20 to 30 VAC at 50/60 Hz; 2.8 VA supply, Class 2
GGx: 20 to 30 VAC at 50/60 Hz; 3.2 VA supply, Class 2
Input Signal
AGx and IGx: 20 to 30 VAC at 50/60 Hz
GGx: 0 to 10 VDC or 0 to 20 mA
Input Signal Adjustments AGx and IGx: CW and COM Terminals, CW rotation
CCW and COM Terminals, CCW rotation
GGx (Voltage Input or Current Input):
Jumper Selectable: 0 (2) to 10 VDC or 0 (4) to 20 mA
Factory Setting: 0 to 10 VDC, CW rotation with signal increase
Action is jumper selectable Direct (CW) or Reverse (CCW) with signal increase.
Input Impedance AGx: 200 ohms, nominal
IGx: 160 ohms, nominal
GGx: Voltage Input, 150,000 ohms; Current Input, 500 ohms
Feedback Signal AGF: 10,000 ohm potentiometer, 1 W
GGx: 0 to 10 VDC or 2 to 10 VDC for 90° (10 VDC at 1 mA)
Corresponds to input signal span selection
Auxiliary Switch Rating
xGC: Two Single-Pole, Double-Throw (SPDT) switches rated at 24 VAC,
1.5 A inductive, 3.0 A resistive, 35 VA maximum per switch, Class 2
Mechanical Output
(Running Torque)
1-, 1.5-, and 2-minute settings: 53 lb∙in (6 N∙m)
5.5- and 11-minute settings: 35 lb∙in (4 N∙m)
Cycles
100,000 full cycles; 2,500,000 repositions rated at 53 lb∙in (6 N∙m)
Audible Noise Rating
35 dBA maximum at 1 m
Rotation Range
Adjustable from 30 to 90°, CW or CCW
Rotation Time IGx: Adjustable with switch settings (Factory set for 1 minute. See
Figure 12.)
60, 90, 120, 330, or 660 seconds (1, 1.5, 2, 5.5 or 11 min.) at 60 Hz;
and 72, 108, 144, 396, or 792 seconds
(1.2, 1.8, 2.4, 6.6, or 13.2 minutes) at 50 Hz
All Other Models: Nominal 60 seconds at 60 Hz and 72 seconds at 50 Hz for 90°
Electrical Connection
1/4 in. spade terminals (Optional pluggable terminal blocks are available.)
Mechanical Connection
3/8 to 1/2 in. (10 to 12.7 mm) round shaft or 3/8 in. (10 mm) square shaft
Enclosure
NEMA 2, IP32
Ambient Operating
Conditions
-4 to 125°F (-20 to 52°C); 90% RH maximum, non-condensing
Ambient Storage
Conditions
IGx: -40 to 186°F (-40 to 86°C); 90% RH maximum, non-condensing
All Other Models: -40 to 176°F (-40 to 80°C); 90% RH maximum, non-condensing
Dimensions (H x W x D)
5.9 x 4.2 x 2.64 in. (150.1 x 106.5 x 67 mm)
Shipping Weight
2.4 lb (1.08 kg)
Agency Compliance UL 873 Listed, File E27734, CCN XAPX
CSA C22.2 No. 139 Certified, File LR85083, Class 3221 02
CE Mark, EMC Directive 89/336/EEC
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or
misuse of its products.
