Installing the NAE/NIE Technical Bulletin4
The NAE and NIE have one Ethernet port, two RS-232 ports,
two USB ports, and (optionally) a 6-pin modem port for an internal
modem (Figure 1). The NAE additionally has two N2 ports. The NIE
is enabled for N1 communication using the Ethernet port. Refer to
Table 2 and Table 3 for the code numbers of the NAE products,
including those with an internal modem.
Note: The NAE internal modem cannot be added in the field.
See the Metasys® System Extended Architecture Overview Technical
Bulletin (LIT-1201527) document for a detailed explanation of the
function of the NAE in a Metasys system. For software configuration
details, see the Configuring the Network Automation Engine (NAE)
Technical Bulletin (LIT-1201519) and N1 Migration with the NIE
Technical Bulletin (LIT-1201535). When the Metasys system is
configured and running, use the online Help for user information.
Table 2: NAE Product Code Numbers
Product Code
Number
Description
MS-NAE5510-0
24 VAC power, N2 Bus
MS-NAE5510-0G
24 VAC power, N2 Bus, Buy American
MS-NAE5510-700
24 VAC power, N2 Bus, repair
MS-NAE5511-0
24 VAC power, N2 Bus, modem
MS-NAE5511-0G
24 VAC power, N2 Bus, modem, Buy American
MS-NAE5511-700
24 VAC power, N2 Bus, modem, repair
Table 3: NIE Product Code Numbers
Product Code
Number
Description
MS-NIE5510-0
24 VAC power
MS-NIE5510-0G
24 VAC power, Buy American
MS-NIE5510-700
24 VAC power, repair
MS-NIE5511-0
24 VAC power, modem
MS-NIE5511-0G
24 VAC power, modem, Buy American
MS-NIE5511-700
24 VAC power, modem, repair
