Page #22 background imageLoading...
Page #22 background image
Table 16: NAE55-3 ordering information (Release 8.1 or 10.1)
Product Code Number Release Description
MS-NAE5520-3 10.1
Supports a LonWorks trunk, two third-party trunks (Modbus RTU or
TCP, M-Bus, or KNX), or two N2 trunks/BACnet MS/TP (RS-485) trunks
(or one N2 trunk and one BACnet MS/TP trunk). Supports up to 255
devices on the LonWorks trunk. Supports up to 100 devices on each N2
or BACnet MS/TP trunk. This model is a BACnet BTL-Listed controller at
Protocol Revision 15 (PR15).
MS-NAE5521-3 10.1
Supports a LonWorks trunk, two third-party trunks (Modbus RTU or
TCP, M-Bus, or KNX), or two N2 trunks/BACnet MS/TP (RS-485) trunks
(or one N2 trunk and one BACnet MS/TP trunk); includes an internal
modem. Supports up to 255 devices on the LonWorks trunk. Supports
up to 100 devices on each N2 or BACnet MS/TP trunk. This model is a
BACnet BTL-Listed controller at Protocol Revision 15 (PR15).
Note: Modem functions are no longer available after this engine
is updated with Metasys Release 10.0 or later.
1 The older MS-NAE5510-2U model may also be available.
Table 17: Network engines accessories ordering information
Product Code Number Description
MS-BAT1020-0
Replacement data protection battery for NAE35, NAE45, and NCE25.
Rechargeable NiMH battery: 3.6 V 500 mAh, with a typical life of 5 to 7 years at
21°C (70°F)
MS-BAT1010-0
Replacement data protection battery for NAE55 and NIE55. Rechargeable gel
cell battery: 12 V, 1.2 Ah, with a typical life of 3 to 5 years at 21°C (70°F)
TL-MAP1810-xx
Pocket-sized web server that provides a wireless mobile user interface to
Metasys field controllers, thermostats, and smart rooftop units. Refer to
the Mobile Access Portal Gateway Catalog Page (LIT-1900869) to identify the
appropriate product for your region.
Note: The MAP Gateway serves as a replacement for the BTCVT, which is
no longer available but continues to be supported.
MS-MULTENGSW-6
DVD with Network Engine software images for all NAEs and NCEs; for
upgrading existing, engine-only (no ADS/X) installations.
MS-EXPORT-0
License enabling Metasys Export Utility software for new installation. Software
may be obtained by electronic download from the Licensing Portal or by
ordering a DVD copy.
MS-COPY-EXPORT DVD reproduction of Metasys Export Utility product, unlicensed
AS-XFR100-1 Power transformer (Class 2, 24 VAC, 92 VA maximum output), with enclosure
AS-XFR010-1 Power transformer (Class 2, 24 VAC, 92 VA maximum output), no enclosure
SC450RM1U (OEM Part No.)
Recommended UPS for NxE85 model: APC Smart-UPS SC 450 VA, 280 W, 120
VAC input/output with NEMA 5-15R output connections
NAE55/NIE55 Installation Guide22
