Table 22: MS-NAE55xx-3 (Release 9.0, 10.0, and 10.1)
Specification Description
United States: UL Listed, File E107041, CCN PAZX, UL 916, Energy
Management Equipment, FCC Compliant to CFR47, Part 15, Subpart B, Class A
Canada: UL Listed, File E107041, CCN PAZX7, CAN/CSA C22.2 No. 205, Signal
Equipment, Industry Canada Compliant, ICES-003
Europe: CE Mark - Johnson Controls, Inc. declares that this product is in
compliance with the essential requirements and other relevant provisions of
the EMC Directive.
Australia and New Zealand: RCM Mark, Australia/NZ Emissions Compliant
Compliance
BACnet International: BTL 35-2004 Listed B-BC
Table 23: MS-NIE551x-3 (Release 9.0 only)
Specification Description
Power Requirement
Dedicated nominal 24 VAC, Class 2 power supply (North America), SELV power
supply (Europe), at 50/60 Hz (20 VAC minimum to 30 VAC maximum)
Power Consumption 50 VA maximum
Ambient Operating
Conditions
0°C to 50°C (32°F to 122°F); 10 to 90% RH, 30°C (86°F) maximum dew point
Ambient Storage
Conditions
-40°C to 70°C (-40°F to 158°F); 5 to 95% RH, 30°C (86°F) maximum dew point
Data Protection Battery
Supports data protection on power failure. Rechargeable gel cell battery: 12 V,
1.2 Ah, with a typical life of 3 to 5 years at 21°C (70°F); MS-BAT1010-0
Clock Battery
Maintains real-time clock through a power failure. Onboard cell: typical life of
10 years at 21°C (70°F)
Processor 1.46 GHz Intel Atom
®
Bay Trail E3815 processor
Memory
16 GB flash nonvolatile memory for operating system, configuration data, and
operations data storage and backup.
2 GB DDR3 SDRAM for operations data dynamic memory for all models
Operating System
Johnson Controls OEM Version of Microsoft
®
Windows
®
Embedded Standard
7 with SP1 (WES7)
Note: The Windows Embedded OS sticker on the bottom of the network
engine permits downgrading the engine to an older Metasys release that
uses a Windows Embedded OS.
Network and Serial
Interfaces
One Ethernet port; 10/100/1,000 Mbps; 8-pin RJ-45 connector
Two optically isolated RS-485 ports; 9,600, 19.2k, 38.4k, or 76.8k baud;
pluggable and keyed 4-position terminal blocks (covered by removable insert)
Two RS-232-C serial ports, with standard 9-pin sub-D connectors, that support
all standard baud rates
Two USB 2.0 serial ports; standard USB connectors (no external modem
support)
NAE55/NIE55 Installation Guide 25
