Vertical Wallbox-Mounted or Surface-Mounted Occupancy Sensing NS Series Network Sensors with LCD
Installation Instructions
2
North American Emissions Compliance
United States
Canada
Installation
Special Tools Needed
A 1/16 in. (1.5 mm) Allen wrench or a Johnson Controls T-4000-119 Allen-Head Adjustment Tool is required during
installation.
Mounting
Note: For wallbox-mounted installations, the occupancy sensing NS Series Network Sensor is intended to be
mounted on a vertically roughed-in wallbox only; do not attempt to mount the network sensor on a horizontally
roughed-in wallbox.
Location Considerations
Locate the network sensor:
• on a partitioning wall, approximately 5 ft (1.5 m) above the floor in a location of average temperature
• away from direct sunlight, radiant heat, outside walls, outside doors, air discharge grills, or stairwells; and from
behind doors
• away from steam or water pipes, warm air stacks, unconditioned areas (not heated or cooled), or sources of
electrical interference
• in a clear path between the PIR occupancy sensor and the space being monitored
Note: The network sensor is shock and vibration resistant; however, be careful not to drop the unit or mount it
where it could be exposed to excessive vibration.
The following ambient operating conditions apply:
• Temperature: 32 to 104°F (0 to 40°C)
• Humidity: 10 to 90% Relative Humidity (RH), noncondensing; 85°F (29°C) maximum dew point
To mount the network sensor:
1. Use a 1/16 in. (1.5 mm) Allen wrench or Johnson Controls T-4000-119 Allen-Head Adjustment Tool to loosen
the security screw on the top of the unit.
2. Insert a coin into the slot next to the security screw location, then carefully pry the top edge of the sensor
assembly away from its mounting base and remove.
This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when this equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in a residential area may
cause harmful interference, in which case users will be required to correct the interference at their own expense.
This Class (A) digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la Classe (A) respecte toutes les exigences du Règlement sur le matériel brouilleur
du Canada.
IMPORTANT: Do not remove the Printed Circuit Board (PCB). Removing the PCB voids the product warranty.
