810754-UTG-C-0214
10 Johnson Controls Unitary Products
* Notates “Hot Heat Pump” performance. These ratings are not AHRI Listed.
COP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric power input
during the same period.
Furnaces that are listed individually in the above table, such as the RGF1L*P, RGF19*P, and RGF1L*E use Coil Only Ratings.
— = Not Applicable.
ACCESSORIES
Refer to Price Manual for specific model numbers.
Start Assist Kit - Provides increased starting torque for areas
with low voltage. See Hard Start Kit Accessory Installation
Manual for Hard Start Kit part number for each model.
Blower Time Delay - Available to increase efficiency when
installed. Installs on indoor section and maintains blower for
approximately one minute after cooling thermostat has been
satisfied.
Low Temperature Cutout (S1-2LT06700224) - Prevents heat
pump operation below -10°F ambient temperature.
TXV Kits - S1-1TVM series thermal expansion valves precisely
meter refrigerant for optimum performance over a wide range of
conditions. See System Charge table for TXV part number for
each model.
Outdoor Thermostat (S1-2TD06700124) - Provides additional
staging of supplemental electric heat.
Thermostats - Compatible thermostat controls are available
through accessory sourcing. For optimum performance and
installation, refer to the UPGNET “Low Voltage Wiring Diagram”
document to select and apply controls.
SOUND LEVEL - TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
Rated in accordance with ARI Standard 270.
HEATING CAPACITY - With High Efficiency Motor Furnaces
UNIT
MODEL
FURNACE
MODEL
COIL
1
MODEL
HEATING
2
STAGE
RATED
CFM
NET MBH
HSPF COP @ 47
47 OD 17 OD
14.5 SEER HP WITH HIGH EFFICIENCY MOTOR FURNACES
3
RHP14J604S21
RGF19*CE20 FC/MC62D
1 1085 43.0 – – 3.20
2 1550 58.0 40.0 8.50 3.50
2* 1085 57.5 38.5 8.45 3.22
RGF19*CE20 FC64D
1 1085 43.5 – – 3.30
2 1550 58.0 40.0 8.20 3.60
2* 1085 57.5 39.0 8.15 3.32
RGF19*DE20 FC/MC62D
1 1085 43.0 – – 3.20
2 1550 58.0 40.0 8.50 3.50
2* 1085 57.5 38.5 8.45 3.22
RGF19*DE20 FC64D
1 1070 43.5 – – 3.32
2 1525 58.0 40.0 8.20 3.60
2* 1070 57.5 38.5 8.15 3.32
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Heating MBH based on AHRI standards of 70 °F DB (Dry Bulb) entering indoor air, 72% RH (Relative Humidity) outdoor air with 25 feet of interconnecting piping
and no supplemental electric heat operation.
3. High Efficiency Motor Furnaces have B.O.D (Blower on Delay) standard.
Size Test Condition 63 125 250 500 1000 2000 4000 8000 dBA SQI
18
Cooling Mode 67 71 67 69 65 59 58 55 70 19.2
Heating Mode 68 70 66 68 67 61 60 57 71 19.2
24
Cooling Mode 69 73 64 67 68 64 61 57 71 19.0
Heating Mode 71 72 65 70 65 64 62 58 73 19.0
30
Cooling Mode 72 70 68 67 67 63 59 55 71 19.0
Heating Mode 74 72 73 68 70 64 61 57 74 19.0
36
Cooling Mode 73 70 72 70 68 63 60 57 73 19.1
Heating Mode 75 73 71 70 70 65 63 61 74 19.1
42
Cooling Mode 71 69 65 68 69 66 63 57 73 19.1
Heating Mode 70 69 68 69 69 65 62 60 73 19.0
48
Cooling Mode 70 73 69 70 70 64 59 57 73 19.1
Heating Mode 70 73 70 71 72 64 62 60 75 19.0
60
Cooling Mode - High Stage 73 70 69 72 75 65 62 59 77 19.1
Heating Mode - High Stage 74 75 72 73 76 68 66 63 79 19.0
