810754-UTG-C-0214
12 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. RHP14J184S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 400 600 800
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C.
17.2 18.8 18.8 20.5 22.2 19.2 19.9 20.1 21.7 22.9 21.2 20.9 21.3 22.8 23.6
S.C.
16.8 14.9 12.9 12.9 11.0 18.8 17.7 15.2 14.7 11.7 20.8 20.5 17.4 16.5 12.5
KW
0.86 0.89 0.89 0.88 0.88 0.94 0.96 0.96 0.95 0.95 1.02 1.02 1.02 1.02 1.02
75
T.C.
16.4 17.9 17.9 19.7 21.3 18.4 19.1 19.0 20.8 22.1 20.4 20.2 20.2 21.8 22.9
S.C.
16.1 14.5 12.5 12.5 10.5 18.0 17.1 14.8 14.4 11.5 20.0 19.8 17.0 16.3 12.4
KW
0.99 1.02 1.02 1.02 1.02 1.08 1.09 1.09 1.09 1.10 1.17 1.16 1.17 1.17 1.18
85
T.C.
15.7 17.0 17.0 18.9 20.4 17.7 18.3 18.0 19.9 21.3 19.6 19.5 19.1 20.8 22.1
S.C.
15.4 14.1 12.1 12.1 10.1 17.3 16.6 14.3 14.2 11.2 19.2 19.1 16.6 16.2 12.2
KW
1.12 1.14 1.14 1.15 1.17 1.22 1.23 1.22 1.24 1.25 1.31 1.31 1.31 1.32 1.33
95
T.C.
15.0 16.1 16.1 18.1 19.6 16.9 17.4 17.0 19.0 20.4 18.8 18.8 18.0 19.8 21.3
S.C.
14.7 13.7 11.6 11.8 9.7 16.5 16.0 13.9 13.9 10.9 18.4 18.4 16.2 16.0 12.1
KW
1.25 1.26 1.26 1.29 1.31 1.36 1.36 1.36 1.38 1.40 1.46 1.46 1.45 1.46 1.49
105
T.C.
14.0 14.7 14.8 16.7 18.4 15.9 16.2 15.7 17.6 19.2 17.7 17.7 16.6 18.5 20.1
S.C.
13.7 13.1 11.0 11.2 9.2 15.5 15.2 13.3 13.4 10.4 17.3 17.3 15.6 15.6 11.6
KW
1.41 1.42 1.42 1.45 1.48 1.52 1.52 1.51 1.54 1.57 1.63 1.63 1.61 1.63 1.65
115
T.C.
13.1 13.4 13.4 15.4 17.2 14.8 15.0 14.4 16.2 18.0 16.6 16.6 15.3 17.1 18.8
S.C.
12.8 12.5 10.5 10.6 8.7 14.5 14.4 12.7 12.9 9.9 16.2 16.2 15.0 15.1 11.2
KW
1.56 1.57 1.57 1.60 1.65 1.68 1.68 1.67 1.70 1.74 1.80 1.80 1.77 1.80 1.82
125
T.C.
12.2 12.1 12.1 14.0 16.1 13.8 13.8 13.0 14.9 16.8 15.5 15.5 14.0 15.7 17.5
S.C.
11.9 11.9 9.9 10.1 8.2 13.5 13.5 12.1 12.3 9.5 15.1 15.1 14.0 14.6 10.7
KW
1.72 1.72 1.72 1.76 1.82 1.84 1.84 1.82 1.87 1.90 1.97 1.97 1.92 1.97 1.99
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil T.C. S.C. KW
– FC/MC/PC32 0.96 0.94 1.11
– FC/MC/PC35 0.96 0.94 1.11
– FC/MC/PC37 0.96 0.95 1.11
– FC/MC/PC43 0.96 0.95 1.11
RFCX24BE – 0.98 0.96 1.00
RFCX30BE – 0.98 0.96 1.01
RFCX24BP – 0.96 0.94 1.11
Furnace Coil T.C. S.C. KW
RGF19*AE10 FC/MC/PC32A 0.98 0.97 1.03
RGF19*AE10 FC/MC/PC37A 0.99 0.98 1.03
