810754-UTG-C-0214
18 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
HIGH CFM
COOLING PERFORMANCE DATA - HIGH CFM 2-STAGE OPERATION
CONDENSING UNIT MODEL NO. RHP14J604S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1650 1850 2050
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 56.5 60.0 59.6 65.6 70.6 58.5 61.2 60.8 66.7 72.5 60.5 62.3 62.0 67.8 74.4
S.C. 55.7 50.3 42.9 42.5 34.9 57.7 53.1 44.9 44.5 36.0 59.6 55.9 47.0 46.5 37.1
KW 3.43 3.47 3.46 3.53 3.61 3.52 3.56 3.55 3.62 3.70 3.61 3.64 3.64 3.71 3.80
75
T.C. 54.4 57.2 56.8 62.6 67.6 56.3 58.2 57.9 63.6 69.1 58.1 59.2 59.0 64.6 70.6
S.C. 53.6 49.1 41.6 41.3 33.5 55.4 51.9 43.7 43.2 34.6 57.3 54.7 45.7 45.2 35.7
KW 3.81 3.85 3.85 3.92 4.00 3.91 3.94 3.93 4.01 4.09 4.00 4.02 4.02 4.09 4.19
85
T.C. 52.3 54.4 54.0 59.6 64.6 54.0 55.2 55.0 60.5 65.8 55.7 56.1 56.0 61.3 66.9
S.C. 51.5 48.0 40.3 40.1 32.2 53.2 50.7 42.4 42.0 33.2 54.9 53.4 44.4 43.9 34.3
KW 4.20 4.23 4.23 4.31 4.39 4.30 4.32 4.32 4.39 4.48 4.40 4.40 4.40 4.48 4.57
95
T.C. 50.2 51.6 51.2 56.5 61.7 51.8 52.3 52.1 57.3 62.4 53.3 52.9 53.0 58.1 63.2
S.C. 49.5 46.8 39.1 38.9 30.8 51.0 49.5 41.1 40.8 31.8 52.5 52.1 43.1 42.6 32.9
KW 4.59 4.62 4.62 4.70 4.78 4.69 4.70 4.70 4.78 4.87 4.79 4.78 4.79 4.87 4.96
105
T.C. 47.5 48.0 47.8 52.6 57.5 48.8 49.0 48.4 53.3 58.1 50.2 50.0 49.1 54.0 58.8
S.C. 46.8 45.2 37.6 37.4 29.2 48.1 47.3 39.6 39.2 30.2 49.5 49.3 41.5 41.1 31.3
KW 5.11 5.12 5.12 5.20 5.28 5.21 5.21 5.20 5.28 5.37 5.30 5.30 5.28 5.36 5.46
115
T.C. 44.7 44.4 44.4 48.7 53.3 45.9 45.7 44.8 49.3 53.9 47.1 47.1 45.2 49.8 54.4
S.C. 44.1 43.7 36.1 35.8 27.6 45.2 45.0 38.0 37.7 28.6 46.4 46.4 39.9 39.5 29.7
KW 5.63 5.62 5.62 5.70 5.79 5.72 5.72 5.70 5.78 5.88 5.82 5.82 5.78 5.86 5.96
125
T.C. 42.0 40.7 41.0 44.8 49.2 43.0 42.5 41.1 45.3 49.6 44.0 44.2 41.3 45.7 50.0
S.C. 41.4 40.7 34.6 34.3 26.0 42.3 42.5 36.5 36.2 27.0 43.3 43.5 38.4 38.0 28.1
KW 6.15 6.12 6.12 6.20 6.29 6.24 6.23 6.20 6.28 6.38 6.34 6.34 6.27 6.36 6.47
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil T.C. S.C. KW
– FC/MC62 0.99 0.99 1.01
RFCX60DE
– 1.00 1.00 0.98
Furnace Coil T.C. S.C. KW
RGF19*CE20 FC/MC62D+TXV 0.99 1.00 1.00
RGF19*CE20 FC64D+TXV 1.02 1.03 1.01
RGF19*DE20 FC/MC62D+TXV 1.00 1.00 1.00
RGF19*DE20 FC64D+TXV 1.02 1.03 1.00
