810754-UTG-C-0214
Johnson Controls Unitary Products 19
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO RHP14J184S21
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
450 600 750
MBH COP KW MBH COP KW MBH COP KW
60
60 20.9 4.6 1.34 22.0 5.0 1.30 23.0 5.4 1.25
70 20.3 4.0 1.48 21.3 4.3 1.44 22.3 4.7 1.39
80 19.7 3.5 1.63 20.7 3.8 1.58 21.6 4.2 1.52
47
60 18.4 4.2 1.29 18.9 4.4 1.27 19.5 4.6 1.24
70 17.5 3.6 1.43 18.1 3.9 1.37 18.8 4.2 1.31
80 16.6 3.1 1.57 17.3 3.3 1.54 18.0 3.5 1.50
40
60 16.4 3.8 1.27 17.0 4.0 1.25 17.5 4.2 1.23
70 15.9 3.3 1.40 16.5 3.5 1.38 17.1 3.7 1.36
80 15.4 3.0 1.53 16.0 3.1 1.51 16.6 3.3 1.48
30
60 14.4 3.4 1.23 14.8 3.5 1.23 15.2 3.6 1.22
70 13.9 3.0 1.36 14.3 3.1 1.35 14.6 3.2 1.34
80 13.5 2.7 1.49 13.8 2.7 1.48 14.1 2.8 1.47
17
60 11.4 2.8 1.18 11.7 2.9 1.19 11.9 2.9 1.20
70 10.6 2.4 1.29 10.9 2.5 1.27 11.2 2.6 1.24
80 10.2 2.1 1.42 10.5 2.2 1.39 10.8 2.3 1.35
10
60 9.5 2.5 1.13 9.6 2.5 1.12 9.7 2.6 1.11
70 9.1 2.1 1.26 9.3 2.2 1.24 9.5 2.3 1.22
80 8.6 1.8 1.39 8.9 1.9 1.37 9.3 2.0 1.34
NOTE: ALL CAPACITIES ARE NET, WITH INDOOR FAN HEAT ALREADY DEDUCTED. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil MBH COP KW
– FC/MC/PC32 1.02 0.91 1.11
– FC/MC/PC35 1.02 0.91 1.11
– FC/MC/PC37 1.02 0.93 1.09
– FC/MC/PC43 1.02 0.93 1.09
RFCX24BE – 0.99 0.97 1.02
RFCX30BE – 1.00 0.97 1.02
RFCX24BP – 1.02 0.91 1.11
Furnace Coil MBH COP KW
RGF19*AE10 FC/MC/PC32A 1.00 0.97 1.03
RGF19*AE10 FC/MC/PC37A 1.00 0.98 1.01
