Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO RHP14J244S21
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
600 800 1000
MBH COP KW MBH COP KW MBH COP KW
60
60 25.7 4.3 1.74 26.5 4.5 1.72 27.2 4.7 1.70
70 24.0 3.7 1.91 25.1 3.9 1.89 26.1 4.1 1.87
80 22.3 3.1 2.08 23.6 3.4 2.06 25.0 3.6 2.04
47
60 23.7 4.1 1.68 23.9 4.2 1.67 24.2 4.3 1.66
70 21.7 3.5 1.84 22.2 3.7 1.78 22.7 3.9 1.72
80 19.8 2.9 2.00 20.5 3.0 1.99 21.2 3.1 1.98
40
60 19.8 3.6 1.61 20.6 3.7 1.62 21.3 3.8 1.63
70 18.6 3.1 1.78 19.4 3.2 1.79 20.2 3.3 1.79
80 17.3 2.6 1.95 18.2 2.7 1.95 19.1 2.9 1.95
30
60 17.7 3.3 1.57 17.9 3.3 1.59 18.0 3.3 1.62
70 16.6 2.8 1.72 16.9 2.8 1.74 17.2 2.9 1.77
80 15.4 2.4 1.88 15.9 2.5 1.90 16.4 2.5 1.92
17
60 14.6 2.9 1.50 15.0 2.9 1.54 15.3 2.8 1.58
70 13.0 2.3 1.66 13.7 2.4 1.66 14.4 2.5 1.66
80 10.6 1.7 1.80 11.6 1.9 1.80 12.6 2.1 1.80
10
60 13.5 2.7 1.48 13.7 2.7 1.49 13.9 2.7 1.50
70 12.1 2.2 1.64 12.4 2.2 1.64 12.7 2.3 1.64
80 10.7 1.8 1.78 11.1 1.8 1.79 11.4 1.9 1.79
NOTE: ALL CAPACITIES ARE NET, WITH INDOOR FAN HEAT ALREADY DEDUCTED. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil MBH COP KW
– FC/MC/PC32 1.03 0.92 1.10
– FC/MC/PC35 1.03 0.91 1.11
– FC/MC/PC37 1.03 0.94 1.08
– FC/MC/PC43 1.03 0.94 1.08
RFCX24BE – 1.00 0.97 1.02
RFCX30BE – 1.00 0.97 1.02
RFCX24BP – 1.01 0.92 1.08
Furnace Coil MBH COP KW
RGF19*AE10 FC/MC/PC32A 1.01 0.95 1.04
RGF19*AE10 FC/MC/PC37A 1.02 0.98 1.03
RGF19*BE12 FC/MC/PC35B 1.00 1.00 0.99
RGF19*BE12 FC/MC/PC43B 1.00 1.03 0.96
RGF19*CE16 FC/MC/PC35C 1.00 1.00 0.99
RGF19*CE16 FC/MC/PC43C 1.00 1.02 0.97
RGF19*CE20 FC/MC/PC35C 1.00 0.98 1.00
RGF19*CE20 FC/MC/PC43C 1.00 1.01 0.98
