810754-UTG-C-0214
Johnson Controls Unitary Products 21
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO RHP14J304S21
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
800 1000 1200
MBH COP KW MBH COP KW MBH COP KW
60
60 36.1 4.9 2.14 36.5 5.2 2.06 36.9 5.5 1.98
70 35.0 4.3 2.40 35.5 4.5 2.30 36.0 4.8 2.20
80 34.0 3.7 2.67 34.6 4.0 2.54 35.1 4.3 2.41
47
60 30.5 4.4 2.03 30.9 4.6 1.97 31.3 4.8 1.91
70 29.7 3.8 2.30 30.1 4.0 2.20 30.5 4.2 2.10
80 29.0 3.3 2.56 29.3 3.5 2.46 29.7 3.7 2.35
40
60 27.7 4.0 2.02 28.0 4.2 1.96 28.3 4.4 1.90
70 26.9 3.5 2.25 27.2 3.7 2.18 27.6 3.8 2.11
80 26.1 3.1 2.48 26.5 3.2 2.40 26.9 3.4 2.32
30
60 24.0 3.6 1.96 24.2 3.7 1.92 24.4 3.8 1.87
70 23.1 3.1 2.19 23.4 3.2 2.14 23.6 3.3 2.09
80 22.3 2.7 2.42 22.6 2.8 2.36 22.9 2.9 2.30
17
60 19.1 3.0 1.89 19.3 3.0 1.87 19.5 3.1 1.85
70 18.4 2.6 2.03 18.7 2.8 1.99 18.9 2.9 1.94
80 17.3 2.3 2.25 17.7 2.4 2.20 18.1 2.5 2.14
10
60 16.7 2.7 1.80 16.8 2.8 1.77 16.9 2.9 1.74
70 15.3 2.3 1.99 15.7 2.3 1.96 16.0 2.4 1.93
80 13.9 1.9 2.19 14.5 2.0 2.15 15.1 2.1 2.10
NOTE: ALL CAPACITIES ARE NET, WITH INDOOR FAN HEAT ALREADY DEDUCTED. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil MBH COP KW
– FC/MC/PC37 1.02 0.93 1.10
– FC/MC/PC43 1.02 0.93 1.10
RFCX36CE – 1.00 1.00 1.00
RFCX36BP – 1.03 0.94 1.10
Furnace Coil MBH COP KW
RGF19*BE12 FC/MC/PC43B 1.00 0.99 1.02
RGF19*CE16 FC/MC/PC43C 1.00 0.98 1.03
