810754-UTG-C-0214
22 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO RHP14J364S21
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
1000 1200 1400
MBH COP KW MBH COP KW MBH COP KW
60
60
43.1 4.23 2.99 44.0 4.34 2.97 44.9 4.46 2.95
70
42.3 3.94 3.14 43.1 4.04 3.13 44.0 4.13 3.12
80
38.9 3.45 3.30 39.8 3.53 3.30 40.7 3.62 3.29
47
60
35.6 3.78 2.76 36.4 3.86 2.76 37.2 3.93 2.77
70
34.6 3.49 2.90 35.3 3.57 2.90 36.0 3.63 2.91
80
31.8 3.07 3.03 32.4 3.12 3.04 33.0 3.16 3.06
40
60
31.3 3.44 2.66 31.9 3.50 2.67 32.5 3.56 2.68
70
30.4 3.20 2.79 31.0 3.24 2.80 31.6 3.28 2.82
80
28.6 2.87 2.92 29.1 2.90 2.94 29.5 2.92 2.96
30
60
27.0 3.12 2.54 27.4 3.14 2.56 27.8 3.17 2.57
70
26.0 2.88 2.64 26.3 2.89 2.67 26.7 2.90 2.70
80
24.2 2.58 2.74 24.5 2.58 2.78 24.8 2.58 2.82
17
60
21.6 2.69 2.35 21.7 2.65 2.40 21.8 2.61 2.45
70
20.1 2.41 2.45 20.2 2.41 2.45 20.3 2.41 2.45
80
18.2 2.19 2.44 18.3 2.14 2.50 18.3 2.10 2.56
10
60
18.2 2.41 2.21 18.4 2.38 2.26 18.6 2.35 2.32
70
16.7 2.19 2.23 16.8 2.14 2.30 17.0 2.11 2.36
80
15.0 1.95 2.26 15.1 1.90 2.33 15.2 1.85 2.40
NOTE: ALL CAPACITIES ARE NET, WITH INDOOR FAN HEAT ALREADY DEDUCTED. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil MBH COP KW
– FC/MC/PC37 1.01 1.01 1.00
– FC/MC/PC43 1.01 1.01 1.00
– FC/MC/PC48 1.00 1.00 1.00
– FC/MC/PC60 1.02 1.04 0.98
– UC48 1.02 1.04 0.98
– UC60 1.02 1.03 0.99
RFCX36CE – 0.99 1.09 0.91
RFCX42DE – 0.98 1.07 0.92
RFCX48DE – 0.97 1.07 0.91
RFCX36BP – 1.01 1.01 1.00
RFCX42CP – 1.00 1.02 0.98
Furnace Coil MBH COP KW
RGF19*BE12 FC/MC/PC43B 0.99 1.04 0.95
RGF19*CE16 FC/MC/PC43C 0.98 1.05 0.93
RGF19*CE16 FC/MC/PC48C 0.98 1.03 0.95
RGF19*CE16 FC/PC60C 0.97 1.03 0.94
RGF19*CE16 UC48C 0.99 1.04 0.94
RGF19*CE16 UC60C 0.97 1.02 0.95
RGF19*CE20 FC/MC/PC43C 0.98 1.06 0.93
RGF19*CE20 FC/MC/PC48C 0.98 1.04 0.94
RGF19*CE20 FC/PC60C 0.97 1.03 0.94
RGF19*CE20 UC48C 0.99 1.05 0.94
RGF19*CE20 UC60C 0.97 1.02 0.95
RGF19*DE20 FC/MC/PC48D 0.97 1.04 0.93
RGF19*DE20 FC/MC/PC60D 0.97 1.04 0.94
RGF19*DE20 UC48D 0.98 1.05 0.93
RGF19*DE20 UC60D 0.97 1.02 0.94
