Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO RHP14J424S21
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
1200 1400 1600
MBH COP KW MBH COP KW MBH COP KW
60
60 42.9 4.5 2.82 42.7 4.4 2.87 42.4 4.3 2.92
70 42.7 4.1 3.07 42.6 4.0 3.11 42.4 3.9 3.15
80 42.5 3.8 3.31 42.5 3.7 3.35 42.4 3.7 3.38
47
60 39.0 4.4 2.61 39.0 4.3 2.67 39.0 4.2 2.73
70 38.4 3.9 2.88 38.5 3.9 2.88 38.6 3.9 2.88
80 37.8 3.5 3.16 38.0 3.5 3.21 38.3 3.4 3.27
40
60 36.1 4.1 2.55 36.3 4.1 2.62 36.5 4.0 2.68
70 35.3 3.7 2.82 35.7 3.6 2.89 36.1 3.6 2.96
80 34.5 3.3 3.09 35.1 3.3 3.16 35.7 3.2 3.23
30
60 31.3 3.7 2.49 31.5 3.6 2.57 31.6 3.5 2.64
70 30.7 3.3 2.76 30.9 3.2 2.83 31.0 3.1 2.90
80 30.1 2.9 3.04 30.3 2.9 3.10 30.5 2.8 3.16
17
60 24.9 3.2 2.30 25.2 3.0 2.45 25.5 2.9 2.59
70 24.7 2.6 2.74 25.5 2.7 2.82 26.4 2.7 2.90
80 23.1 2.2 3.05 24.5 2.3 3.11 25.9 2.4 3.16
10
60 22.3 2.6 2.51 22.9 2.6 2.55 23.4 2.6 2.60
70 22.3 2.3 2.79 22.7 2.4 2.82 23.2 2.4 2.85
80 22.4 2.2 3.04 22.6 2.2 3.07 22.9 2.2 3.11
NOTE: ALL CAPACITIES ARE NET, WITH INDOOR FAN HEAT ALREADY DEDUCTED. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil MBH COP KW
– FC/MC62 1.00 1.00 1.00
– FC/MC/PC60 1.02 1.04 1.00
RFCX48DE – 1.01 1.09 0.92
RFCX60DE – 0.98 1.08 0.91
RFCX48DP – 1.02 1.01 1.01
Furnace Coil MBH COP KW
RGF19*CE16 FC/MC62D 0.97 1.01 0.98
RGF19*CE16 FC/PC60C 0.99 0.99 1.01
RGF19*CE20 FC/MC62D 0.97 1.04 0.94
RGF19*DE20 FC/MC/PC60D 0.98 1.03 0.96
RGF19*DE20 FC/MC62D 0.97 1.05 0.94
RGF19*DE20 UC60D 0.96 0.98 0.98
