810754-UTG-C-0214
24 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO RHP14J484S21
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
1400 1600 1800
MBH COP KW MBH COP KW MBH COP KW
60
60
59.6 4.4 3.93 60.4 4.7 3.74 61.3 5.1 3.54
70
58.1 4.0 4.27 59.0 4.2 4.07 59.9 4.5 3.86
80
56.7 3.6 4.62 57.6 3.8 4.40 58.5 4.1 4.19
47
60
50.6 3.9 3.77 51.3 4.2 3.58 52.0 4.5 3.40
70
49.4 3.5 4.11 50.1 3.7 3.9 50.8 4.0 3.73
80
48.2 3.2 4.45 48.9 3.4 4.26 49.6 3.6 4.07
40
60
45.8 3.6 3.68 46.3 3.9 3.51 46.8 4.1 3.35
70
44.9 3.3 4.04 45.3 3.4 3.86 45.8 3.6 3.68
80
43.9 2.9 4.40 44.4 3.1 4.20 44.9 3.3 4.01
30
60
40.3 3.3 3.54 40.0 3.5 3.38 39.7 3.6 3.22
70
39.2 2.9 3.91 38.5 3.0 3.73 37.8 3.1 3.55
80
38.0 2.6 4.26 37.0 2.7 4.07 36.0 2.7 3.87
17
60
31.9 2.7 3.42 32.6 2.9 3.31 33.2 3.1 3.19
70
30.7 2.4 3.74 31.1 2.5 3.63 31.4 2.6 3.52
80
29.5 2.1 4.07 29.5 2.2 3.97 29.6 2.3 3.85
10
60
28.4 2.5 3.36 27.7 2.5 3.22 27.0 2.6 3.06
70
28.0 2.2 3.69 27.7 2.3 3.52 27.5 2.4 3.39
80
27.5 2.0 4.01 27.7 2.1 3.86 27.9 2.2 3.72
NOTE: ALL CAPACITIES ARE NET, WITH INDOOR FAN HEAT ALREADY DEDUCTED. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler
Coil MBH COP KW
– FC/MC/PC60 1.00 0.98 1.03
– FC/MC62 1.00 1.00 1.00
– FC64 1.04 1.07 0.98
RFCX48DE – 0.98 1.01 0.97
RFCX60DE – 0.98 1.09 0.90
RFCX48DP – 1.00 0.94 1.07
Furnace Coil MBH COP KW
RGF19*CE16 FC/MC62D 0.98 1.05 0.94
RGF19*CE16 FC/PC60C 0.98 0.93 1.07
RGF19*CE16 FC64D 1.01 1.06 0.96
RGF19*CE20 FC/MC62D 0.98 1.09 0.90
RGF19*CE20 FC64D 1.01 1.11 0.91
RGF19*DE20 FC/MC/PC60D 0.98 0.98 1.01
RGF19*DE20 FC/MC62D 0.98 1.10 0.89
RGF19*DE20 FC64D 1.01 1.13 0.90
