810754-UTG-C-0214
Johnson Controls Unitary Products 25
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA - HIGH CFM 2-STAGE OPERATION
CONDENSING UNIT MODEL NO RHP14J604S21
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
1600 1800 2000
MBH COP KW MBH COP KW MBH COP KW
60
60 71.2 4.5 4.60 72.4 4.7 4.56 73.6 4.8 4.52
70 70.3 4.1 5.07 71.3 4.2 5.02 72.3 4.3 4.97
80 69.4 3.7 5.56 70.1 3.7 5.49 70.9 3.8 5.42
47
60 62.1 4.1 4.41 62.6 4.2 4.38 63.1 4.3 4.35
70 61.2 3.7 4.90 61.6 3.7 4.86 62.1 3.8 4.81
80 60.2 3.3 5.37 60.6 3.3 5.31 61.1 3.4 5.25
40
60 56.4 3.9 4.29 56.8 3.9 4.27 57.2 4.0 4.25
70 55.7 3.4 4.78 56.0 3.5 4.74 56.2 3.5 4.70
80 55.0 3.1 5.26 55.1 3.1 5.20 55.2 3.1 5.14
30
60 49.4 3.5 4.14 49.8 3.5 4.16 50.1 3.5 4.19
70 47.9 3.0 4.72 47.9 3.0 4.67 47.8 3.0 4.63
80 46.4 2.6 5.31 46.0 2.6 5.19 45.6 2.6 5.07
17
60 40.1 2.9 4.00 37.4 2.9 3.73 34.8 2.9 3.46
70 41.4 2.6 4.64 40.1 2.6 4.49 38.9 2.6 4.34
80 41.2 2.3 5.15 41.5 2.4 5.15 41.7 2.4 5.15
10
60 36.1 2.6 3.99 36.5 2.7 4.03 37.0 2.7 4.07
70 34.7 2.3 4.47 35.8 2.3 4.50 36.8 2.4 4.53
80 33.4 2.0 4.94 35.0 2.1 4.96 36.6 2.2 4.98
NOTE: ALL CAPACITIES ARE NET, WITH INDOOR FAN HEAT ALREADY DEDUCTED. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Air Handler Coil MBH COP KW
– FC/MC62 1.01 0.97 1.04
RFCX60DE – 1.00 1.00 1.00
Furnace Coil MBH COP KW
RGF19*CE20 FC/MC62D+TXV 1.00 0.95 1.04
RGF19*CE20 FC64D+TXV 1.00 0.98 1.01
RGF19*DE20 FC/MC62D+TXV 1.00 0.95 1.04
RGF19*DE20 FC64D+TXV 1.00 0.98 1.01
