RL SERIES INSTALLATION MANUAL
Point Type Point Address Long Name
ADF 1 nciSetpoints.Occupied_Co
ADF 2 nciSetpoints.Standby_Coo
ADF 3 nciSetpoints.Unoccupied_
ADF 4 nciSetpoints.Occupied_He
ADF 5 nciSetpoints.Standby_Hea
ADF 6 nciSetpoints.Unoccupi5#6
ADF 7 nciMinClgSetpt
ADF 8 nciMaxHtgSetpt
ADF 9 nvoSpaceTemp
ADF 10 nvoDischAirTemp
ADF 11 nvoEffClgSetpt
ADF 12 nvoEffHtgSetpt
ADF 13 nviSpaceTemp
ADF 16 nciAux1Temp
ADF 17 nciAux2Temp
ADF 18 nvoUnitStatus.Heat_Outpu
ADF 20 nvoUnitStatus.Cool_Outpu
ADF 22 nvoUnitStatus.Fan_Output
BD 9 nvoUnitStatus.Mode
BD 10 nvoUnitStatus.In_Alarm
ADF 23 nciPropBand
ADF 26 nciRemoteSetptMin
ADF 27 nciRemoteSetptMax
ADF 28 nciTempOffset
ADF 33 nviSetpoint
ADF 40 nvoHtgFrzPro1Tmp
ADF 41 nvoHtgFrzPro2Tmp
ADF 53 nvoAlarms
ADF 54 nvoSrcLoopTmp
ADF 55 nciSummerSetpt
ADF 56 nciAuxTempOffset
ADF 58 nvoHtgFrzSetpt
ADI 3 nciHours
BD 1 nvoEffectOccup
BD 2 nviOccManCmd
BD 4 nviEmergOverride
BD 5 nvoFanStatus
BD 6 nvoAccStatus
BD 7 nvoLP_WVStatus
BD 8 nvoAlarmStatus
BD 12 nviAlarmReset
BD 14 nviFanSpeedCmd.State
BD 15 nviComprEnable.State
BD 25 nviCompr2Enable.State
BD 16 nviValveEnable.State
BD 18 nvoComp1Status
BD 19 nvoRV1Status
BD 23 nviOccSchedule.Current_s
BD 26 nvoComp2Status
BD 27 nciLogic_19
BD 30 nciLogic_35
BD 31 nvoCompFanProv
BD 32 nviBO5
BD 34 nvoDirtyFilter
BD 35 nviBO9
BD 36 nvoBO9
N2 Open
Occupied Cooling Setpoint Input (Read/Write)
Standby Cooling Setpoint Input (Read/Write)
Unoccupied Cooling Setpoint Input (Read/Write)
Occupied Heating Setpoint Input (Read/Write)
Standby Heating Setpoint Input (Read/Write)
Unoccupied Heating Setpoint Input (Read/Write)
Minimum Cooling Setpoint Input (Read/Write)
Maximum Heating Setpoint Input (Read/Write)
Space or Zone Temperature Value (Read Only)
Discharge Air Temp Field Supplied Only (Read Only)
Effective Cooling Setpoint Value (Read Only)
Effective Heating Setpoint Value (Read Only)
Space or Zone Temperature Value Override(Write)
Heating Freeze Protection Temperature Setpoint Value (Read/Write)
Heating Freeze Protection Temperature Setpoint Value (Read/Write)
1st Stage Compressor Heating Output (Read Only)
1st Stage Compressor Cooling Output (Read Only)
Fan Output (Read Only)
Unit Mode of Operation (Read Only)
Unit Alarm mode (Read Only)
Heating/Cooling Prop Band Input (Read/Write)
Warm/Cool Adjust Min (Read/Write)
Warm/Cool Adjust Max (Read/Write)
Space or Zone Temperature Sensor Calibration Input (Read/Write)
General Setpoint Input (Read/Write)
Heating Freeze Protection Temperature 1 Value (Read Only)
Heating Freeze Protection Temperature 2 Value (Read Only)
Alarms Enumerated [0=no alarms, 1=condensate alarm, 2=Compressor Hi Discharge Pressure
alarm, 3=Compressor low Suction Pressure alarm, 4=Freeze protection alarm, 8=Faulty Freeze
Sensor alarm,
9=Loss of Charge]
(Read Only)
Main Loop Temp for Economizer Control (Read Only)
Setpoint for Economizer (Read/Write)
Economizer Temperature Sensor Calibration Input (Read/Write)
Heating Freeze Protection Temperature Setpoint Value (Read Only)
Compressor Stage Lead/Lag hour setting (Read/Write)
Effective Occupancy State (Read Only)
Occupancy Override Command Input (Read/Write)
Emergency Override Input (Read/Write)
Fan Output Status (Read Only)
Accessory 2 Output Status (Read Only)
Accessory 1 Output Status (Read Only)
Alarm Output Status (Read Only)
Alarm Reset Input (Read/Write)
Network equivelant of a thermostatic 'G' call. (Write)
Network equivelant of a thermostatic 'Y1' call. (Write)
Network equivelant of a thermostatic 'Y2' call. (Write)
Network equivelant of a thermostatic 'O' call. (Write)
Compressor 1 Command Status (Read Only)
Reversing Valve Output Status (Read Only)
Occupancy Supervisory Scheduler Command Input (Read/Write)
Compressor 2 Command Status (Read Only)
Compressor Stage Lead/Lag Enable/Disable (Read/Write)
Water Side Economizer Enable/Disable (Read/Write)
Compressor/Fan Proving Switch Status (Read Only)
Command for output BO5 used for Emg Heat-Interlocked with Fan DP9Read/Write)
Value Output for BO5 used for Emg Heat (Read Only)
Command for output BO9(Read/Write)
Value output for BO9 (Read Only)
Point Description
Optional FX10 Microprocessor Control - N2
