RL SERIES INSTALLATION MANUAL
Model Nomenclature
RLX
1-3 4 5-7 8 9 10
Model Type
RLL – RL Low Temp
RLX – RL Extended Range
Cabinet Configuration
V – Vertical
H - Horizontal
Unit Capacity (MBTUH)
080, 095, 120, 160
180, 240, 300
Discharge Configuration
T – Top (Vertical)
E – End (Horizontal)
S – Side (Horizontal)
Return Air Configuration
L – Left
R – Right
Voltage
3 – 208-230/60/3
4 – 460/60/3
5 – 575/60/3
Future Option
0 – Future
Blower Options
A – Standard Static, Standard Motor
B – Low Static, Standard Motor
1
C – High Static, Standard Motor
2
D – Standard Static, Large Motor
2,3
E – High Static, Large Motor
3
Water Coil Option
C – Copper
N – CuproNickel
Vintage
* - Factory Use Only
Non-Standard Options
SS – Standard
QP – 2" MERV 13 Filter
SF – Stainless Steel Drain Pan
4
SG – 2" MERV 13 Filter, Stainless Steel Drain Pan
4
Air Coil/Insulation Option
3 – Uncoated
4 – AlumiSeal
TM
Control Option
4 – FX10 Standard without Communication
5 – FX10 with Open N2 Communication
6 – FX10 with Lonworks Communication
7 – FX10 with BacNet Communication
8 – FX10 Standard with User Interface
9 – FX10 with Open N2 & User Interface
0 – FX10 with Lonworks & User Interface
3 – FX10 with BacNet & User Interface
Water Control Option
N – None
Hot Gas Bypass/Reheat Option
N – None
G – Hot Gas Bypass
R – Hot Gas Reheat
B – Hot Gas Bypass w/Hot Gas Reheat
Sound Kit Option
A – None
B – Sound Kit
Rev.: 14 August 2014D
11 12 13 15
V 120 T L 3 0 A C A N
14
N
16
4
17
3
18
SS
19-20
*
21
Notes:
1 – Not available on RLXV/RLLV095, 180, RLXH/RLLH080
2 – Not available on RLXV/RLLV080, 160
3 – Not available on RLXH/RLLH120, RLXV/RLLV300
4 – Not available on RLXV/RLLV160-300. Stainless steel is standard on RLXV/RLLV160-300
JOHNSON CONTROLS
5
