RL SERIES INSTALLATION MANUAL
Object Type Type Enumeration Instance Name Enumeration
Analog Value 2 1 Present_Value 85 WFI##########.Occupied Cool.Present_Value Occupied Cooling Setpoint Input (Read/Write)
Standby Cooling Setpoint Input (Read/Write)
Analog Value 2 3 Present_Value 85 WFI##########.Unoccupied Cool.Present_Value Unoccupied Cooling Setpoint Input (Read/Write)
Analog Value 2 2 Present_Value 85 WFI##########.Occupied Heat.Present_Value Occupied Heating Setpoint Input (Read/Write)
Standby Heating Setpoint Input (Read/Write)
Analog Value 2 4 Present_Value 85 WFI##########.Unoccupied Heat.Present_Value Unoccupied Heating Setpoint Input (Read/Write)
Analog Value 2 7 Present_Value 85
WFI##########.Min Clg Setpt.Present_Value
Minimum Cooling Setpoint Input (Read/Write)
Analog Value 2 6 Present_Value 85
WFI##########.Max Htg Setpt.Present_Value
Maximum Heating Setpoint Input (Read/Write)
Analog Input 0 1 Present_Value 85 WFI##########.Space Temp.Present_Value
Space or Zone Temperature Value (Read Only)
Analog Input 0 2 Present_Value 85 WFI##########.Discharge Air Temp.Present_Value Discharge Air Temp Field Supplied Only (Read Only)
Analog Input 0 5 Present_Value 85 WFI##########.Effective Clg Setpt.Present_Value Effective Cooling Setpoint Value (Read Only)
Analog Input 0 6 Present_Value 85 WFI##########.Effective Htg Setpt.Present_Value Effective Heating Setpoint Value (Read Only)
Analog Output 1 2 Present_Value 85 WFI##########.Space temp Ovrd.Present_Value
Space or Zone Temperature Value Override(Write)
Heating Freeze Protection Temperature Setpoint Value (Read/Write)
Heating Freeze Protection Temperature Setpoint Value (Read/Write)
1st Stage Compressor Heating Output (Read Only)
1st Stage Compressor Cooling Output (Read Only)
Fan Output (Read Only)
Multistate Input 13 2 Present_Value 85 WFI##########.Mode.Present_Value Unit Mode of Operation (Read Only)
Unit Alarm mode (Read Only)
Heating/Cooling Prop Band Input (Read/Write)
Analog Value 2 9 Present_Value 85 WFI##########.Remote Setpt Min.Present_Value Warm/Cool Adjust Min (Read/Write)
Analog Value 2 8 Present_Value 85 WFI##########.Remote Setpt Max.Present_Value Warm/Cool Adjust Max (Read/Write)
Analog Value 2 10 Present_Value 85 WFI##########.Zone Temp Offset.Present_Value Space or Zone Temperature Sensor Calibration Input (Read/Write)
Analog Output 1 1 Present_Value 85 WFI##########.Common Setpoint.Present_Value General Setpoint Input (Read/Write)
Analog Input 0 3 Present_Value 85 WFI##########.Freez Temp 1.Present_Value Heating Freeze Protection Temperature 1 Value (Read Only)
Analog Input 0 3 Present_Value 85 WFI##########.Freez Temp 2.Present_Value Heating Freeze Protection Temperature 2 Value (Read Only)
Analog Input 0 8 Present_Value 85 WFI##########.nvoAlarms.Present_Value
Alarms Enumerated [0=no alarms, 1=condensate alarm, 2=Compressor Hi Discharge Pressure
alarm, 3=Compressor low Suction Pressure alarm, 4=Freeze protection alarm, 8=Faulty Freeze
Sensor alarm, 9=Loss of Charge] (Read Only)
Analog Input 0 9 Present_Value 85 WFI##########.Economizer Temp.Present_Value Main Loop Temp for Economizer Control (Read Only)
Analog Input 2 5 Present_Value 85 WFI##########.Economizer Setpt.Present_Value Setpoint for Economizer (Read/Write)
Analog Value 2 11 Present_Value 85 WFI##########.EconomizerTempOffset.Present_Value Economizer Temperature Sensor Calibration Input (Read/Write)
Analog Input 0 7 Present_Value 85 WFI##########.Freez Temp Limit.Present_Value Heating Freeze Protection Temperature Setpoint Value (Read Only)
Compressor Stage Lead/Lag hour setting (Read/Write)
Multistate Input 13 1 Present_Value 85 WFI##########.Effective Occupancy.Present_Value Effective Occupancy State (Read Only)
Multistate Output 14 1 Present_Value 85 WFI##########.Occupancy Command.Present_Value Occupancy Override Command Input (Read/Write)
Multistate Output 14 6 Present_Value 85 WFI##########.Emergency Override.Present_Value Emergency Override Input (Read/Write)
Binary Input 3 1 Present_Value 85 WFI##########.Fan Cmd Status.Present_Value Fan Output Status (Read Only)
Accessory 2 Output Status (Read Only)
Accessory 1 Output Status (Read Only)
Alarm Output Status (Read Only)
Multistate Output 14 7 Present_Value 85 WFI##########.Alarm Reset.Present_Value Alarm Reset Input (Read/Write)
Multistate Output 14 2 Present_Value 85 WFI##########.Fan Command (G).Present_Value Network equivelant of a thermostatic 'G' call. (Write)
Multistate Output 14 3 Present_Value 85 WFI##########.Comp1 Command (Y1).Present_Value Network equivelant of a thermostatic 'Y1' call. (Write)
Multistate Output 14 4 Present_Value 85 WFI##########.Comp2 Command (Y2).Present_Value Network equivelant of a thermostatic 'Y2' call. (Write)
Multistate Output 14 5 Present_Value 85 WFI##########.Rev Vlv Cmd (O).Present_Value Network equivelant of a thermostatic 'O' call. (Write)
Binary Input 3 2 Present_Value 85 WFI##########.Comp1 Cmd Status.Present_Value Compressor 1 Command Status (Read Only)
Binary Input 3 4 Present_Value 85 WFI##########.Reversing Valve.Present_Value Reversing Valve Output Status (Read Only)
Occupancy Supervisory Scheduler Command Input (Read/Write)
Binary Input 3 3 Present_Value 85 WFI##########.Comp2 Cmd Status.Present_Value Compressor 2 Command Status (Read Only)
Compressor Stage Lead/Lag Enable/Disable (Read/Write)
Multistate Value 19 1 Present_Value 85 WFI##########.Economizer Ena/Dis.Present_Value Water Side Economizer Enable/Disable (Read/Write)
Multistate Input 13 3 Present_Value 85 WFI##########.Compressor/Fan Prove.Present_Value Compressor/Fan Proving Switch Status (Read Only)
Multistate Output 14 8 Present_Value 85 WFI##########.Emergency Heat BO5.Present_Value Command for output BO5 used for Emg Heat-Interlocked with Fan DP9Read/Write)
Binary Input 3 5 Present_Value 85 WFI##########.BO5 ElecHeat.Present_Value Value Output for BO5 used for Emg Heat (Read Only)
Multistate Output 14 9 Present_Value 85 WFI##########.BO9.Present_Value Command for output BO9(Read/Write)
Binary Input 3 9 Present_Value 85 WFI##########.BO9 Output.Present_Value Value output for BO9 (Read Only)
Point Description
Object Identifier Property
BACnet
Full Reference
Optional FX10 Microprocessor Control - BACnet
